Fire-Lite LDM

LDM Driver Modules LDM Series lamp driver modules when combined with a graphic display provide annunciation and control for intelligent fire alarm control panels These modules a serial communications interface and may be located up 6,000 feet from the panel ALARM CIRCUIT ON and TROUBLE lamp LED per point or more dense alarm only option field selectable Control switch option for remote control per point Lamps LEDs may be programmed to display status of indi circuits or control relays as well as system status System trouble lamp LED signal On line power LED indicator Alarm and trouble resound with flash of new conditions Local sounder for both alarm circuit on and trouble condi with silence acknowledge switch connection Serial EIA 485 interface for reduced installation costs May be powered by 24 VDC from the panel or by remote Efficient switch power converter reduces power consump supplies Microprocessor controlled electronics fully supervised Plug in terminal blocks for ease of installation and service Trouble monitor option for remote power supplies basic models are available the LDM 32F control module the LDM E32F expander module Each may be selected provide 32 alarm indications or 16 alarm 16 trouble and 16 points LDM 32F LDM E32F with a custom graphic array may be to indicate point status and in some versions to control state of output points addition the LDM R32F module may be used to provide 32 relays for electrical isolation when connecting the to other equipment B 300 LDM 32F and LDM E32F modules mount on four stand inside the custom annunciator graphic box Alternately modules may be installed in a CHS 4L chassis The mod size is approximately 4.4 11.2cm x 7.1 18cm between the LDM Series annunciators and host FIre Alarm Control Panel are made through a EIA 485 multi drop loop and a two wire regulated 24 power loop Up to 32 LDM systems may be connected to single control panel field wiring terminations use removable compression type blocks for ease of installation wiring and circuit test Series modules when used with a custom graphic provide the Fire intelligent fire alarm control with up to 32 unique or redundant annunciators each a capacity of 64 points for a total capacity of 2048 points or remote power supplies and serial communications the custom annunciators to be located anywhere on the premises of system operational controls such as Signal Silence Reset and local annunciation controls such as Local and Lamp Test may be accomplished through key or push switches Listings and Approvals listings and approvals apply to the modules specified in document In some cases certain modules or applications 06 24 11 Page 1 of 2 not be listed by certain approval agencies or listing may in process Consult factory for latest listing status UL Listed S2424 ULC Listed MEA Listed 317 01 E CSFM 7300 0075 0160 FM Approved City of Chicago approved Class 1 Class 2 City of Denver approved Line Information Lamp Driver Module with 32 alarm lamp driver sink to power common on alarm May be selected switch for 16 alarm circuit on 16 trouble and 16 switch if desired Also includes system trouble lamp driver and switch input Integral piezo sounds for each new alarm or trouble and is silenced the Local Acknowledge switch or permanently disabled a dip switch selection Flash of new alarms or troubles is through dip switches 16 switch inputs may be used panel SILENCE RESET or remote relay control Instruc are included Lamp Driver Module with 32 alarm drivers or 16 16 trouble and 16 switch inputs One LDM E32F is per LDM 32F in alarm only mode Three LDM E32F are allowed per LDM 32F in alarm trouble Includes cable to connect to LDM 32F LDM E32F Lamp Driver Module which connects to any LDM or LDM E32F to convert transistor outputs to 32 Form A contacts 1.0 A 30 VDC Provides 32 output terminal connections and a single common terminal screw ribbon cables to connect to the LDM 32F LDM E32F for electrical isolation when interfacing the system to other LDM CBL48 Ribbon cable sets to provide a 24 60.96cm or 48 121.96cm connection between and LEDs or lamps on a custom graphic Includes all cables necessary for one LDM 32F or Cables have connector on one end only split and connect other end to graphic annunciator specifications on LDM Graphic Annunciator Lamp Driver contact Fire by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Fire Alarms Phone 800 627 3473 FAX 877 699 4105 in the U S A 2 of 2 DF 51384 B1 06 24 11
