Fire-Lite MS-9600 Rev 2 DACT-UD - Intelligent Addressable FACP w Optional 2nd Loop

MS 9600 2 DACT UD Intelligent Address FACP with Optional 2nd Loop Fire MS 9600 is a compact cost effective intelligent fire alarm control panel with a capacity of 318 Fire devices on one Signaling Line Circuit or a total of 636 addressable points with an optional loop SLC 2 An optional modem DACT UD is avail for remote site upload download and or remote monitor Signaling Line Circuit SLC loop supports up to 159 detectors including photoelectric photoelectric heat ionization photoelectric duct fixed heat fixed heat rate of rise and fixed high heat detectors It also supports to 159 addressable modules including monitor two wire normally open devices dual monitor functions two circuits from one module two addresses used con for Notification Appliance Circuits and relay two Form modules The panel uses surface mount technology and is for ease of installation programming and mainte It features the latest in advanced fire protection tech including maintenance alert and automatic detector functions FEATURES Optional modem Selectable strobe synchronization per NAC Remote site upload download Four Class B or two Class A NAC circuits Loop SLC can be configured for NFPA Style 4 6 or 7 operation SLC supports up to 318 addressable devices per loop 159 and 159 monitor control or relay modules the new addressable dual monitor module heat and duct detector SLC loop maximum length 10,000 ft 3,048 m 12 AWG mm Requires twisted shielded wire 3,000 ft 914.4 untwisted unshielded wire Appliance Circuits NACs Four onboard NACs with additional NAC capability using control modules CMF 300 or CMF 300 6 Silence Inhibit and Auto Silence timer options Continuous March Time Temporal or California code for circuit board NACs with two stage capability Selectable strobe synchronization per NAC Fire Technology Sensitivity testing with printable results onsite or offsite Automatic drift compensation and Software Autoprogram learn mode reduces installation time Fully programmable from local keypad local PS 2 keyboard PC via PK Plus Windows utility A1 90 Remote site upload download capability with DACT UD Two level user programmable passwords Custom English labels per point may be manually entered selected from an internal library file Two programmable Form C relay outputs 99 software zones Interface Optional modem DACT UD Remote Acknowledge Silence Reset and Drill via address monitor modules ACS Series annunciators or LCD remote annunciator EIA 232 printer PC interface variable baud rate on main board 80 character LCD display with backlighting Real time clock calendar with automatic daylight savings History file with 1,000 event capacity EIA 485 supporting up to 32 ACS Series annunciators EIA 485 supporting up to 32 LCD 80F annunciators Maintenance alert warns when smoke detector dust accu is excessive Automatic device type code verification One person audible or silent walk test with walk test log and Point trouble identification Local piezo sounder Waterflow nonsilenceable selection per monitor point System alarm verification selection per detector point PAS Positive Alarm Sequence and presignal delay per NFPA 72 compliant 11 26 07 Page 1 of 6 REQUIREMENTS SLC requires use of a specific wire type to ensure proper operation It is recommended that all SLC wiring be shielded to minimize the effects of electrical inter Wire size should be no smaller than 18 AWG 0.821 and no larger than 12 AWG 3.31 mm The wire size on the length of the SLC circuit Use the table below determine the specific wiring requirements for the SLC Requirements Distance in shielded shielded shielded shielded m feet m feet m feet m feet m feet m Wire Size AWG 3.31 mm Belden 9583 Genesis Signal 98230 WPW D999 AWG 2.08 mm Belden 9581 Genesis Signal 98430 WPW D995 AWG 1.31 mm Belden 9575 Genesis and 4606 Signal 98630 WPW D991 AWG 0.821 mm Belden 9574 Genesis and 4602 Signal 98300 WPW D975 unshielded 18 AWG 3.31 0.821 mm Optional 4XTMF module conventional reverse polarity city transmitter 2 of 6 DF 52395 A 11 26 07 and Indicators INDICATORS AC POWER green FIRE ALARM red SUPERVISORY yellow ALARM SILENCED yellow TROUBLE yellow MAINTENANCE PRESIGNAL yellow DISABLED yellow BATTERY yellow GROUND yellow SWITCH CONTROLS ACKNOWLEDGE STEP ALARM SILENCE DRILL RESET lamp test 12 key pad with full alphabet 4 cursor keys ENTER Features PROGRAMMING Create the entire program in your using a Windows software package order pro kit PK CD containing PK Plus separately Upload system programming locally to the MS 9600 in less one minute Command the MS 9600 to program takes less than 30 seconds In the Auto Program mode MS 9600 scans for all possible devices at all addresses the device types and addresses found and then loads values for all options General Alarm It also checks for or more devices set to the same address EDIT While still providing fire protection the MS may be programmed from the front panel Simple menu displayed on the LCD allow the trained user to perform functions without referring back to the programming man LABEL LIBRARY Quickly select labels from a library of more than 50 adjectives nouns such as 3 HALLWAY or enter custom labels letter by letter Use function to repeat previously used label CHECK Automatically catch common errors as control modules not linked to any zone or input point Alert MS 9600 continuously monitors each smoke detector and capable of reporting maintenance conditions This reduces risk of false alarms due to dust accumulation Refer to the panel installation manual for more information Test Operation MS 9600 performs an automatic test of each detector two hours Failure to meet the test limits causes an TEST FAIL trouble type System Reset clears this trou Power TB1 120 VAC 60 Hz 3.0 A Wire size minimum AWG 2.08 mm with 600 V insulation lead acid only TB2 Maximum charging circuit flat charge 27.6 VDC 1.0 A Maximum battery capacity 25 AH MS 9600 cabinet holds maximum of 18 AH batteries For 25 120 AH batteries use the CHG or CHG 75 Battery Charger and BB 55F Battery Box Jumper JP3 on the FACP main circuit board must be to disable the FACP battery charger when using the CHG Loop standard TB8 24 VDC nominal VDC maximum Maximum length 10,000 ft 3048 m twisted shielded pair length Maximum loop current 400 short circuit or 100 mA normal Maximum loop resis 40 ohms Supervised and power limited maximum available current shared between all NACs auxiliary power outputs is 7.0 A at 24 VDC Appliance Circuits TB4 Power limited cir Maximum voltage drop in wiring 2.0 VDC Nominal voltage 24 VDC Current limit fuseless electronic circuitry Maximum signaling current per circuit A End of Line Resistor 4.7K ohm 1 2 watt P N 71252 UL for NACs Refer to Fire Device Compatibility Docu for listed compatible devices and Trouble Output Relays TB5 Contact 2.0 A 30 VDC resistive 0.5 A 30 VAC resistive relays Resettable Smoke Detector Power 24 VDC TB3 Terminals 1 2 Maximum ripple volt 10 mVrms Up to 3.0 A for powering four wire smoke Power limited c
