AMM 4S MONITOR Accommodates up to Twenty 20 FCI Conventional 2 Wire Smoke Detectors Class A Style D or Class B Style B Initiating Device Circuit 25 Ohm Line Resistance for Initiating Device Circuit Accommodates any N O Dry Contact Device Compact Size Allows Easy Installation Addressable Monitor Module AMM 4S features a single D Class A circuit It may also be configured as a Style B B initiating circuit with end of line resistor This module an address for a group of up to twenty 20 conven 2 wire smoke detectors These include the FCI SBS 301 and CPD Series smoke detectors and System Sensor Mod 2100 S and 2100 TS alarm initiating devices with normally open N O dry con such as heat detectors linear heat detection devices beam smoke detectors 4 wire smoke detectors water switches tamper switches manual stations etc may also installed in this circuit AMM 4S module is designed for installation in the signal line circuit of any FCI analog addressable control panel signaling line circuits of FCI analog addressable panels are to accommodate up to 99 monitor modules per circuit initiating circuit of the AMM 4S has a maximum line resis of 25 ohms allowing the module to stay in alarm with one detector activated AMM 4S is designed to mount in a 4 square junction box 2 1 8 deep APPROVALS 427 91 E Vol III INFORMATION current current temperature humidity amp amp to 120o F 0 to 49o C to 93 non condensing 1 2 H x 4 W x 1 1 4 D 3.3 x 5.5 x 1.25 cm INFORMATION Number Model Monitor Module Single circuit Style D Class A are provided for information only are not intended to be used for installation purposes and are believed to be accurate However no responsibility is assumed Fire Control Instruments Inc for their use Specifications subject to change without notice All Rights Reserved 2nd Ave Waltham MA 02451 1133 USA TEL 781 487 0088 FAX 781 370 4132 www firecontrolinstruments com ISO 9001 certified Company 1.2
