Gamewell-FCI MCS-PTIR and MCS-PTIR-IV Multi-Criteria Photo Thermal Infrared Detector

Addressable Devices and MCS PTIR IV Photo Thermal Infrared Detector Description and MCS PTIR IV are intelligent multi criteria detectors that combine thermal and infrared PTIR sensors in one unit to sense multiple of a fire This approach enables enhanced sensitivity to real fire with immunity to nuisance particulates sensors and communication can greatly reduce nuisance alarms compared single sensing methods Sophisticated algorithms maximize the advantages of all sensor types creating our best detection strategy offering heightened immunity nuisance particulate and enhanced sensitivity to real fire Photoelectric sensor detects airborne particles associated with smoke Thermal sensor detects heat and rate of rise 135 fixed temperature threshold for alarm determination ability to reject certain nuisance alarm triggers such as theater smoke supports use of the detector in applications where moderate to heavy nuisance conditions that might cause single sensing detectors to trigger a false alarm PTIR detector meets both UL 268 7th edition and UL 521 listing requirements can indicate distinct smoke and heat alarms This dual nature supports a local setting for photoelectric detection and a general evacuation setting based on detection This can minimize work interruptions in multi level buildings Infrared sensors discern light patterns in the environment as an additional data in B200S WH sounder base Remote LED Annunciator Kit Ring BENEFITS Multi criteria detection Low standby current Dual LEDs for 360 Expanded color UL 268 7th Edition and 521 Listed Analog Rotary address New modern profile and Velociti are trademarks of International Inc by Honeywell Inc All rights Unauthorized use of document is strictly document is not intended be used for installation We try to keep our information up to and accurate We cannot all specific applications anticipate all requirements specifications are subject to without notice of origin Mexico and MCS PTIR IV Technical Specifications 2.0 inches 51 mm installed in B300 6 base 6.2 inches 156 mm installed in B300 6 4.1 inches 104 mm installed in B501 WHITE base 3.4 oz 95 g Humidity Range 15 to 90 Relative Non condensing Temperature Range 32 to 100 0 to Velocity 0 to 300 ft min 0 to 91.4 m min SPECIFICATIONS Voltage Range 15 to 32 VDC Current 24 VDC 200 uA one every 5 seconds with green LED blink on Alarm Current 2 mA 24 VDC one every 5 seconds with red LED solid on Current 4.5 mA 24 VDC one every 5 seconds with amber LED solid Load Rating 0.0063 devices in this datasheet meet the standards of UL 7th Edition LISTINGS AND APPROVALS listings and approvals below apply to the MCS PTIR MCS PTIR IV In some cases certain modules may be listed by certain approval agencies or listing may in process Consult the factory for the latest listing S1195 Approved 7272 1703 0508 INFORMATION Multi criteria photoelectric thermal and smoke detector Velociti bright white color Multi criteria photoelectric thermal and smoke detector Velociti and CLIP ivory color 4 Mounting base white 4 mounting base white 10 pack 4 Mounting base ivory 4 Mounting base black 6 Flanged mounting base white 6 Flanged mounting base white 10 pack 6 Flanged mounting base ivory Intelligent addressable sounder base white Intelligent addressable sounder base ivory Intelligent addressable sounder base white Intelligent addressable sounder base low ivory Isolator base white Isolator base ivory Relay base white Relay base ivory Surface mounting kit flanged Trim ring white Trim ring ivory IR color kit includes cover and trim ring white IR color kit includes cover and trim ring 10 pack IR color kit includes cover and trim ring 10 pack Remote LED annunciator Detector test magnet Telescoping test magnet Gamewell FCI Clintonville Road CT 06472 1610 A 04 19 Honeywell International Inc
