Gamewell-FCI Non-Coded Century Pull Station

Non Coded Station Station construction design blends with surroundings pull level prevents accidental break glass design and vibration resistant with wire leads or screw terminals or semi flush installation Optional general alarm keyswitch action option cast aluminum construction Non Coded Century Station is a modern com design that complies with the architectural for a manual alarm initiating device compact design does not detract from the deco aspects of a building interior yet is easily Century Station is shock and vibration resistant no mercury element type contacts are used A switch of rugged construction provides excep high resistance to an accidental operation a sudden shock Because the pull level does extend from the box accidental operation from with moving objects is virtually impossible Century Stations are available in three 3 mod which can be used for both surface or semi flush Model M46 28 has a N O alarm contact 4 wire leads for in and out connections Model and M46 30 use screw terminals for in and alarm connections and an extra Form C auxiliary In addition Model M46 30 provides a Form general alarm keyswitch which is mounted behind pull level The keyswitch is not accessible until pull level is operating The general alarm key is provided with duplicate terminals for in and wiring station is essentially a switch enclosed in the alarm box shell It is operated by the simple act of forward a readily identifiable bulls eye alarm marked Upon operation this lever locks the alarm position and remains in this position until alarm is reset by an authorized person To reset alarm release the screw at the top right edge of station or use the CAT60 key with the Key Reset Both of these actions release the front of the which is hinged at the bottom thereby expos the toggle switch which can then be manually permitting the cover to be replaced in its nor position are for information only are not intended for installation purposes and are subject to change without notice No responsibility is assumed by Gamewell FCI for their use Clintonville Road Northford CT 06472 Tel 203 484 7161 Fax 203 484 7118 Rev C page 1 of 3 Gamewell FCI a semi flush installation a standard 4 or 4 11 square box with a single gang plaster ring is The total depth between the back of wall box and the face of the plaster ring must be least 2 1 2 If a 1 1 2 deep box is used the plas ring must be at least 1 deep If a 2 deep box is the plaster ring must be at least 1 2 deep A gang switch box cannot be used glass Option the glass rod in the slots on the hinged front sure the lever is always behind the glass Return the hinged front to the station and tighten slot head screw securely to assure proper of the station assembly Action Option lifting the double action lever before pulling on the lever Reset Option turning a standard CAT60 key included to the station Key reset option for flush mounted only M 46 M 46 with Key reset option Surface backbox Pin 28762 Rating face pull lever target and backbox for surface are die cast aluminum sold separately alarm red smooth gloss Raised cast lettering is high Target background for pull is white gloss enamel H x 3 1 4 W x 15 16 D 1 4 H x 3 1 4 W x 15 16 D 5 8 H x 3 1 4 W x 2 3 8 D DPDT amps at 125 VAC VDC amps at 250 VAC VDC keyswitch amps at 125 VAC Weights All flush stations 1 lb surface 1 lb optional break glass rod may be used with all sta However it does not detract from the station when it is not used The break glass station is frequently specified as an added fea as this enclosure protects the station from an attempt to initiate a false alarm It also additional protection against tampering The design prevents the jamming of the sta and there is no danger to the operator from bro particles of glass Space is provided within the housing for storage of one replacement glass Application Century Station provides a non coded manual initiating input to a Gamewell FCI conventional alarm system for example Flex 300 3000 Flex Zans 400 INS 2 CZI Specifications manual fire alarm station shall be a Gamewell Century Station model number M 46 and shall be by U L Inc single double action non coded station shall of a die cast aluminum housing fitted with a lever which when operated locks in position reactivating alarm initiating contact body of the manual station shall be hinged to a assembly which is locked by a slot head Resetting the station after operation shall opening the front cover for access to the switch manual fire alarm station is adaptable for surface semi flush installation In addition there are provi for a self clearing break glass mechanism and key operated general alarm switch accessible only the pull out lever has been activated surface type stations a die cast backbox P N must be ordered separately This backbox has holes top and bottom for a 3 4 conduit Con bushings must be used to avoid abrasion of the wires The unused conduit entrance should closed with a 3 4 flush pipe plug not furnished addition you can use a 1 2 or 1 conduit with bushings Gasket gasket Pin 50397 with adhesive backing for weatherproof installation on a surface P N 28762 Clintonville Road Northford CT 06472 Tel 203 484 7161 Fax 203 484 7118 Rev C page 2 of 3 Information Number switch with in and out leads initiating circuit switch with terminals switch with in and out terminals initiating circuit switch with in and out terminals initiating circuit and SPDT general keyswitch with in and out action reset reset double action surface mounting gasket rod Clintonville Road Northford CT 06472 Tel 203 484 7161 Fax 203 484 7118 Rev C page 3 of 3
