Honeywell TH8320U1008 User Manual [PDF]

Operating Manual TH8000 Series Programmable Thermostat CAREFUL Never use sharp instruments such as a pencil pen to press touchscreen keys To prevent damage to the always press keys with your fingertip manual covers the following models For 1 Heat 1 Cool systems For up to 3 Heat 2 Cool systems For up to 3 Heat 2 Cool systems with dehumidification thermostat from wallplate and turn over to find model number thermostat contains a Lithium battery which may contain Perchlorate material Material handling may apply www dtsc ca gov hazardouswaste perchlorate assistance with this product please visit http yourhome honeywell com call Honeywell Customer Care toll free at 1 800 468 1502 Help and save these instructions U S Registered Trademark Patent No 6595430 D509151 and other patents pending 2011 Honeywell International Inc All rights reserved your new thermostat of contents features 2 at a glance 3 reference to controls 4 reference to status display 5 Operation setting 6 setting 7 setting 8 program schedules 9 schedule overrides 12 hold 14 features 15 lock 16 cleaning 17 display control 18 TH8000 Series replacement 20 functions 21 case of difficulty 26 remote sensors 28 warranty 29 thermostat is ready to go new thermostat is pre and ready to go page 3 to check settings EQUIPMENT DAMAGE To prevent possible damage do not oper cooling system when outdoor is below 50 10 Manual your new thermostat You just purchased the world most advanced easy to use ther It has been designed to give you many years of reliable service and touch climate control 7 day program schedules maximize comfort and economy Armchair programming Just pull thermostat from the wall to set schedules Energy saving settings for maximum cost savings One touch temp control overrides program schedule at any time Precise comfort control keeps temperature within 1 of the level you set Change check reminders let you know when to service or replace filters and other critical components Large touchscreen display with backlight is easy to read in the dark Select models display and control summer humidity Select models accommodate optional outdoor or indoor remote sensors TH8000 Series your new thermostat thermostat is ready to go new thermostat is pre programmed and ready to go Just set the time and day check the settings below and change if needed Set clock See page 6 Select fan setting Preset to Auto See page 7 Select system setting Preset to Heat See page 8 Program schedules Preset to energy saving levels you at work or asleep assumes you at 6 am leave at 8 am return at 6 pm go to bed at 10 pm See pages 10 13 TEMP CONTROL You can override the program schedule at any time manually adjust the temperature see pages 12 14 Manual reference to controls day s to set program schedule see page 11 to select fan see page 7 to select system see page 8 to set program see page 11 TO PICK MULTIPLE DAYS To SCREEN to adjust settings pages 11 14 for more options models only to override schedule pages 12 14 to set clock page 6 to lock keypad for 30 to clean screen page 17 reference to status display inside temperature day of week setting TH8000 Series setting setting time To schedule on not display off SCREEN Intelligent in effect page 15 display messages Cool On Cooling system is activated Heat On Heating system is activated Aux Heat On Auxiliary heating system is activated Manual setting CLOCK SCREEN time then press DONE set the current time display press CLOCK press s or t to adjust the time Press hold s or t to advance the time more DONE to save exit or press CANCEL to without changing the time The real time clock should never require since it automatically updates for savings time and stores all date time To change the current week day display see 22 setting To70 SCREEN FAN If a fan schedule is programmed will run the fan schedule TH8000 Series FAN to select fan operation then press On Fan is always on Auto Fan runs only when the heating or system is on Circ Fan runs randomly about 35 of the not counting any run time with the or cooling system can press FAN to override the fan settings programmed for different time periods page 11 If you select On or Circ the you select will remain active until you FAN again to select Auto see page 27 more information Manual setting To70 SCREEN the SYSTEM button to select then press Heat Thermostat controls only the system Cool Thermostat controls only the system Off Heating and cooling systems are off Auto Thermostat automatically selects or cooling depending on the temperature Em Heat only for heat pumps with heat Thermostat controls and Auxiliary Heat is locked out Select models only money by setting program schedules easy to program your system for maximum energy savings You can program four periods each day with different settings for weekdays and weekends TH8000 Series to the time you awaken and the temperature you want the morning until you leave for the day to the time you leave home and the temperature you while you are away usually an energy saving level to the time you return home and the temperature you during the evening until bedtime to the time you go to bed and the temperature you want usually an energy saving level am am pm pm
