27 21 29 OVER COAX CONVERTER SPECIFICATIONS 1 GENERAL SUMMARY Ethernet overt VDSL2 Converter Coaxial SECTION INCLUDES MCE Coax Ethernet over Coax Converter REFERENCES Federal Communications Commission FCC European Union Compliance CE SYSTEM DESCRIPTION Performance Requirements Provide 1 VDSL2 port with BNC connector and 1 10 100Base TX copper port system shall utilize 50 ohm RG6 RG58A U RG58C U RG58 U or equivalent coaxial cable for VDSL2 port system shall utilize EIA568 category 5 5e 4 pair cables for 10Base T or 100Base TX SUBMITTALS Manufacturer Installation and Operating Manual Printed installation and operating information for the PoE Warranty Manufacturer Printed Warranty DELIVERY STORAGE AND HANDLING Store in original packaging in a climate controlled environment Storage Temperature not to exceed 25 C to 70 C PROJECT SITE CONDITIONS Temperature Requirements Product shall operate in an environment with an ambient temperature range of C to 50 C without the assistance of fan forced cooling Humidity Requirements Products shall operate in an environment with relative humidity of 10 to 90 1 of 5 2010 WARRANTY Standard GE Security Inc Comprehensive Warranty GE Security warrants the product to be free of factory under manufacture 3 Years Warranty 2 PRODUCTS MANUFACTURER Acceptable Manufacturer GE Security Inc 8985 Town Center Parkway Bradenton FL 34202 5129 Phone 1 888 437 3287 Email gesecurity customerservice ge com Substitutions Not Permitted MANUFACTURED UNITS Model Number Descriptions Reference Table A Product Number Descriptions Model Compatibility Chart Reference Table B Product Compatibility Chart GENERAL SPECIFICATIONS The Ethernet over VDSL2 Converter shall be a MCE Coax module Ethernet Port module shall support the Ethernet data IEEE 802.3 802.3u 10 100Base TX protocol using and Auto MDI MDI X features module features one fixed 10 100TX electrical ports in a compact mini box module shall support UTP distance up to 100 meters VDSL2 Port The module shall comply with ITU T G 993.1 G 993.2 VDSL VDSL2 and SG15Q4 DMT The module shall utilize coaxial cable for the digital subscriber line The module shall equipped with a 4 Position DIP Switch for selectable CO CPE Fast Inter leave mode The module shall provide below indicating LED for monitoring proper system operation Rate and SNR Power CO CPE mode VDSL2 link status Ethernet port link status Ethernet port speed The module shall equip with an AC DC adapter with DC 5V input 2 of 5 2010 that the VDSL link is established that the VDSL link is at training status about 10 seconds that the VDSL link is at idle status that the port is link down the VDSL Bridge is running at CO mode the VDSL Bridge is running at CPE mode that the port is link up that the Converter is actively sending or receiving data over that port that the port is link down that the port is operating at 100Mbps that the port is link down or 10Mbps DATA SPECIFICATIONS Data Interface Ethernet IEEE802 u Data Rate 10 100 Mbps Data Inputs 2 VDSL2 SPECIFICATIONS Encoding VDSL DMT Number of VDSL2 port 1 Maximum Distance 1.0 miles 1.6km STATUS INDICATORS System Green VDSL ON OFF Green Green Lit Green Lit Green Green 10 100Base TX Port CONNECTORS Power DC plug female VDSL2 Port BNC Ethernet Port RJ 45 ELECTRICAL SPECIFICATIONS Power Adapter Voltage Range 100 240VAC Voltage 5VDC 2.5A max 3 of 5 2010 MECHANICAL SPECIFICATIONS Surface Mount Dimensions WxDxH 3.82 x 2.76 x 1.02 97x 70 x 26mm Finish Module shall be constructed of a metal enclosure Weight 0.44lbs 200g ENVIRONMENTAL SPECIFICATIONS MTBF 50,000 Hours Operating Temp 0 C to 50 C Storage Temp 25 C to 70 C Relative Humidity 10 to 90 non condensing REGULATORY AGENCIES APPROVALS AND LISTINGS Federal Communications Commission FCC Part 15 Class A European Union Compliance CE with following standard EN 55022 2006 Class A EN61000 3 2 2006 EN61000 3 3 A2 2005 EN 55024 A2 2003 ACCESSORIES AC to DC Power Adapter x1 3 EXECUTION PREPARATION Standalone Module Surface Mount Shall be mounted on a properly prepared surface adequate for the size and weight of module The of the unit shall allow provision for cable installation and maintenance as indicated on the detail drawings and in compliance with the installation manual INSTALLATION General Locate VDSL2 over Ethernet Converter module as indicated on the approved detail drawings and module in compliance with the GE Security User manual The device is used for Point to Point connection only Master device to Slave device The BNC connector supports 50 ohm cable Depending on the quality of coaxial cable the maximum distance one VDSL segment is 1.6km with coaxial cable The distance will change by the quality of coaxial cables Set the MCE Coax to be CO mode or CPE mode from the DIP switch at the rear panel 4 of 5 2010 TESTING Testing the 10 100TX Fast Ethernet Copper Link Verify that the data leads and UTP ports are properly connected Successful data link operation should be confirmed at this point by communicating with other equipment Testing the VDSL2 coaxial cable link Set the one MCE Coax to be CO mode and the other MCE Coax to be CPE mode Power on the MCE Coax by connecting its power source Connect coaxial cable between the VDSL BNC ports of the two MCE Coaxs VDSL LNK LED will from blinking to illuminate CLEANING Follow all instructions for proper use of solvents and adhesives used for termination and splicing UNITS REFERENCE TABLES A Product Number Descriptions Series over Coax Converter DISTANCE feet 100M electrical Miles 1.6KM coaxial Maximum distance is limited to optical loss of the fiber and any additional loss by connectors splices and patch B Product Compatibility Chart over VDSL Converter Ethernet Equipment 802.3u Fast Ethernet standard for 10 100TX protocol G 993.1 G 993.2 VDSL VDSL2 and SG15Q4 DMT OF SECTION 5 of 5 2010
