Kidde 3100972-EN R03 R Series Remote Annunciator Enclosures Installation Sheet

Installation Allow approximately 2 in 50 cm clearance on both sides of the to permit inserting and removing the key and opening the through 90 degrees install the enclosure Secure the enclosure to the electrical box as shown in Figure 2 Connect the RS 485 riser to the appropriate annunciator terminals to the annunciator installation sheet for wiring details Leave enough wire to easily remove and position the when setting the DIP switch you installing a single position RA ENC1 skip to step 10 Complete and insert the expander labeling sheets Attach the expander cable to the annunciator Route the expander cable using one of the channels so that the is not pinched Connect the expander cable to the expander Attach an expander for interconnection to a second expander if applicable Tilt the lowest expander up and slide the mounting slot onto the flange in the enclosure Tilt the expander down and press the bottom of the expander over Secure the bottom of the expander to the adapter ring using the stud nut screw Repeat steps 7 through 9 for the remaining expander if applicable Tilt the annunciator up and slide the mounting slot onto the top in the enclosure Tilt the annunciator down and press the bottom of the annunciator Secure the bottom of the annunciator to the adapter ring using the the stud nut screw Cover the screw hole with the product label plate 1 Enclosure dimensions Series Remote Annunciator Installation Sheet R Series Remote Annunciator Enclosures provide surface protection for annunciators and expanders Each consists of back plate hinged cover and key lock models are available for housing various combinations of one R Remote Annunciator and one or two R Series Remote See Table 1 for a list of enclosure model numbers enclosures are 16 gauge welded steel with a white painted finish enclosure includes a lock and two keys The two and three enclosures have wiring channels for correct routing of cables which are provided with the enclosures enclosures attach to a standard electrical box and provide a lip that takes the place of the integral mounting ring supplied the annunciators and expanders 1 Family Remote Annunciator Enclosure models enclosure for R Series Remote enclosure for one R Series Annunciator and one Family Remote enclosure for one R Series Annunciator and two R Series Expander in cm in 2 cm Height of enclosures 6.3 in 16.0 cm 12.0 in 30.5 cm 17.7 in 45.0 cm enclosure Leave a clearance of approximately 2 in 50 cm on both sides of 3100972 EN REV 03 ISS 28SEP15 2 in cm 1 in cm in cm information contact information see www edwardsfiresafety com 2015 Walter Kidde Portable Equipment Inc rights reserved H W D environment humidity wiring within the enclosures must be American 4 inch square or 3 gang boxes 9.8 2.0 in 16.0 24.9 5.1 cm 9.8 2.0 in 30.5 24.9 5.1 cm 9.8 2.0 in 45.0 24.9 5.1 cm welded steel enamel to 120 0 to 49 to 93 noncondensing 2 Mounting the enclosure and installing annunciators and expanders RISER RISER 2 3100972 EN REV 03 ISS 28SEP15
