Kidde 3101025-EN R03 CTM City Tie Module Installation Sheet

Specifications fault impedance size current box connection Wire resistance environment humidity VDC nom mA mA max to 18 AWG 0.75 to 2.5 sq mm American 2 1 2 in 64 mm deep box mA into a 14.5 coil to 120 0 to 49 to 93 noncondensing information contact information see www edwardsfiresafety com 2015 Walter Kidde Portable Equipment Inc rights reserved City Tie Module Sheet CTM City Tie Module provides a single municipal box connection activating a local energy type master box connected to a public fire reporting system the CTM in accordance with NFPA 70 National Electrical Code This device will not operate without electrical power As frequently cause power interruptions we suggest you discuss safeguards with your fire protection specialist CTM is shipped from the factory as an assembled unit it contains user serviceable parts and should not be disassembled more information refer to the technical reference manual listed the control panel door install the module Verify that all field wiring is free of opens shorts and ground 1 Make all wiring connections as shown in the wiring diagram See Using the 4 24 1 2 in 13 mm self tapping screw provided the wall plate to the module Using the two 6 32 1 2 in 13 mm machine screws provided the module to the electrical box the CTM to a dedicated notification appliance circuit NAC as in 1 on page 2 Do not install other notification appliances on the circuit 3101025 EN REV 03 ISS 16NOV15 2 1 CTM installation wiring diagram dedicated notification circuit 4 electrical box 3 energy type box coil fire alarm system plate Power limited and supervised for opens shorts and ground faults Nonpower limited and supervised for opens and ground faults only Use end of line resistor value required by the notification appliance max 4.4 A max NAC output signal must be compatible with the input rating of the energy type master box 2 3101025 EN REV 03 ISS 16NOV15
