Kidde 3101095-EN R04 SA-232 RS-232 Interface Card Installation Sheet

RS 232 Interface Card Sheet SA 232 card provides an RS 232 interface to the panel The card be used for connecting a printer to the control panel to print events The card can also be used for uploading and panel configuration history and current status to a PC the configuration utility RS 232 card is installed on the plastic assembly and connects to main circuit board via a ribbon cable install the RS 232 card Power down the panel and disconnect the batteries Locate the card location on the plastic assembly behind the main board and connector J3 on the main circuit board at the of the main board Attach the card to the plastic assembly using two 6 plastite as shown in the diagram below Connect the ribbon cable P N 7140187 from the card to J3 on the main circuit board as shown in the diagram Connect field wiring See Power up the panel and then connect the batteries 1 SA 232 card installation of board plastite screws card cable J3 on circuit board RS 232 card can be wired to a printer to print system events or to a computer to download to the panel 2 SA 232 wiring connections black wire green wire white wire red wire wiring The printer must be enabled and configured through for proper operation to a printer Locate the serial port on the back of the printer Connect the DB 25 end of the RS 232 cable to the serial port on back of the printer Connect the other end of the RS 232 cable to the RS 232 card 3 Printer wiring serial port back of printer E E D R M E D ET ELE CT LAR M OW E R IT CH OD E male cable RS 232 card 4 DB 25 pin connections 1 7 COM black wire 25 male view 20 DTR green wire 1 SA 232 card to printer DB 25 connections card DB 25 pin 7 Black wire ground connection pin 20 Green wire printer supervision pin 3 White wire communication pin 2 Red wire communication download wiring to a computer you have a connected printer disconnect it Locate a serial port COM port on the back of the computer Connect the DB 9 end of the RS 232 cable to the COM port on the of the computer Connect the other end of the RS 232 cable to the RS 232 card 3101095 EN REV 04 ISS 08OCT15 2 5 Computer download wiring COM port back of computer male cable RS 232 card 6 DB 9 pin connections male view 2 SA 232 card to computer DB 9 connections card DB 9 pin 5 Black wire ground connection pin 2 White wire communication pin 3 Red wire communication used voltage communications length voltage current rating communication environment VDC communications maximum 13 capacitance 0.7 feet max 10 V 13 mA 20 mA to 18 AWG 0.75 to 2.5 mm2 baud to 120 0 to 49 to 93 RH noncondensing at 90 information contact information see www edwardsfiresafety com 2015 Walter Kidde Portable Equipment Inc rights reserved 2 3101095 EN REV 04 ISS 08OCT15
