Kidde 3101172-EN R07 FX-5 and FX-10 Series Technical Reference Manual

and FX 10 Series Reference Manual 3101172 EN REV 07 ISS 11FEB17 2017 United Technologies Corporation All rights reserved document may not be copied in whole or in part or otherwise reproduced prior written consent from United Technologies Corporation except specifically permitted under US and international copyright law and patents The Kidde name and logo are trademarks of United Technologies trade names used in this document may be trademarks or registered of the manufacturers or vendors of the respective products This document applies to FX Series panel firmware 4 x and later information For contact information see www kiddelifesafety com 1 2 3 4 5 information iii overview and operation 1 overview 2 system requirements 3 overview 4 controls and indicators 5 module controls and indicators 8 and K FSRA10C controls and indicators 9 descriptions 10 the panel 11 15 checklist 16 the cabinet 17 remote modules 18 the F DACT1 F 19 an auxiliary booster power supply 19 programming 21 programming requirements 22 you begin 23 started 24 the panel 26 initiating device circuits 30 notification appliance circuits 33 coded alarm signals 36 programming 39 you begin 40 started 42 account options 43 dialer options 45 system event transmit options 46 IDC event transmit options 48 NAC event transmit options 48 system 4 2 event activation code options 49 IDC 4 2 event activation code options 50 NAC 4 2 event activation code options 51 dialer default settings 51 53 maintenance 54 a walk test 55 lamp tests 56 messages 57 the control panel fuse 57 parts 58 3101172 EN REV 07 ISS 11FEB17 A B calculations 61 calculation worksheet 62 appliance voltage drop calculation 65 appliance circuit calculations 66 templates 71 programming worksheet 72 programming worksheet 73 programming worksheet 75 programming worksheet 76 C diagrams 83 cautions and notes 84 D specifications 101 E event codes 103 Contact ID event codes 104 4 2 event codes 105 107 3101172 EN REV 07 ISS 11FEB17 information of liability the maximum extent permitted by applicable law in no event will United Technologies Corporation be liable for lost profits or business opportunities loss of use business interruption loss of data or any other indirect incidental or consequential damages under any theory of liability whether based in contract tort product liability or otherwise Because some jurisdictions do not allow the exclusion or limitation of for consequential or incidental damages the preceding limitation may not apply to you In any event the liability of United Technologies Corporation shall not exceed the purchase price of the product The foregoing will apply to the maximum extent permitted by applicable law regardless of whether United Corporation has been advised of the possibility of such damages and regardless of whether any fails of its essential purpose in accordance with this manual applicable codes and the instructions of the authority having is mandatory every precaution has been taken during the preparation of this manual to ensure the accuracy of its United Technologies Corporation assumes no responsibility for errors or omissions warning equipment can generate and radiate radio frequency energy If this equipment is not installed in accordance this manual it may cause interference to radio communications This equipment has been tested and found comply with the limits for Class A computing devices pursuant to Subpart B of Part 15 of the FCC Rules These are designed to provide reasonable protection against such interference when this equipment is operated in commercial environment Operation of this equipment is likely to cause interference in which case the user at own expense will be required to take whatever measures may be required to correct the interference FCC information ensure proper operation this dialer must be installed according to the enclosed installation instructions To that the dialer is operating properly and can successfully report an alarm it must be tested immediately installation and periodically thereafter according to the enclosed test instructions order for the dialer to be able to seize the phone line to report an alarm or other event when other customer telephone answering system computer modem etc connected to the same line is in use the dialer be connected to a properly installed RJ 31X jack The RJ 31X jack must be connected in series with and of all other equipment attached to the same phone line Series installation of an RJ 31X jack is depicted in wiring diagram If you have any questions concerning these instructions you should consult your telephone or a qualified installer programming emergency numbers or making test calls to emergency numbers remain on the line and explain to the dispatcher the reason for the call Perform programming and testing activities in the off peak such as early morning or late evenings 3101172 EN REV 07 ISS 11FEB17 requirements equipment approved before July 23 2001 This dialer complies with Part 68 of the FCC rules A label to the dialer contains among other information the FCC registration number and ringer equivalence REN for this equipment If requested this information must be provided to the telephone company equipment approved after July 23 2001 This dialer complies with Part 68 of the FCC rules and the adopted by the Administrative Council for Terminal Attachments ACTA A label attached to the contains among other information a product identifier in the format US AAAEQ TXXXX If requested this must be provided to the telephone company plug and jack used to connect the dialer to the premises wiring and telephone network must comply with the FCC Part 68 rules and requirements adopted by ACTA The dialer must be connected to a compliant or RJ 38X jack using a compliant cord If a modular telephone cord is supplied with the dialer it is to meet these requirements See installation instructions for details ringer equivalence number REN is used to determine how many devices you can connect to a telephone line the total REN value for all devices connected on a telephone line exceeds that allowed by the telephone the devices may not ring on an incoming call In most but not all areas the total REN value should not 5.0 To be certain of the total REN value allowed on a telephone line contact the local telephone products approved after July 23 2001 the REN is part of the product identifier in the format The digits represent the REN without a decimal point Example 03 is an REN of 0.3 earlier products the REN is listed separately the dialer is harming the telephone network the telephone company will notify you in advance that temporary of service may be required If advance notice isn practical the telephone company will notify you soon as possible You will also be advised of your right to file a complaint with the FCC if you believe it is telephone company may make changes to its facilities equipment operations or procedures that could the operation of the dialer If this happens the telephone company will provide advance notice in order for to make necessary modifications to maintain uninterrupted service you are experiencing problems with the dialer contact Technical Support at 1 800 655 4497 for repair or information If the dialer is harming the telephone network the telephone company may request that you the dialer until the problem is resolved dialer contains no user serviceable parts In case of defects return the dialer for repair may not connect the dialer to a public coin phone or a party line service provided by the telephone company Canada information Industry Canada label identifies certified equipment This certification means that the equipment meets telecommunications network protective operational and safety requirements Industry
