Kidde 387459-EN R04 RKEY Remote Annunciator Key Switch Installation Sheet

Figure 1 Installing the RKEY Remote Annunciator Switch Installation Sheet RKEY Remote Annunciator Key Switch is a key switch mounted a single gang plate and designed for use with the LSRA C and annunciators The RKEY is a normally open dry contact used with annunciators the key switch enables or inhibits the control buttons on the annunciators For LSRA C the annunciator programming determines which buttons controlled by the key switch key switch is finished in brushed stainless steel and has the symbols for lock and unlock printed on the front additional connection details see the installation sheet or technical manual for the annunciator you are using 2 Wiring the RKEY to the annunciator Annunciator Key switch External switch terminals or connector most applications the RKEY must be mounted within 3 ft 0.9 m the annunciator and the wiring must be in a metal conduit Consult appropriate electrical codes and the authority having jurisdiction runs must be broken at all terminal connections to provide proper of the circuit install the RKEY Pull the wiring from the annunciator box to a compatible electrical 2 Connect the annunciator wiring to TB1 on the RKEY See Mount the RKEY in the electrical box using the security screws See Figure 1 voltage current wire size configuration VDC mA in 64 mm deep 1 gang box terminals AWG 2.5 mm closed information contact information see www edwardsfiresafety com 2015 Walter Kidde Portable Equipment Inc rights reserved 387459 EN REV 04 ISS 28SEP15 1
