Genesis LED Expander Series G4SE Strobe Expander Genesis LED EG4S Series Features Sleek design allows the installation of two independent strobes a speaker or horn in a single compact footprint Fewer parts to stock standard Genesis LED EG4S speaker strobes EG4 horn strobes Field configurable convenience settings remain visible even after the unit is installed Meets UL C synchronization requirements with legacy Genesis appliance on the same circuit Ultra low current the maximum number of strobes on a circuit No extension ring or trim plate needed standard 4 inch square electrical boxes with plenty room behind for wiring Available in 4 colors for flexible Mass Notification needs Red Green and Blue lens options Genesis LED G4SE Strobe Expander offers both Notification Emergency Communication MNEC and Life System notification capabilities without all the wall clutter separate or larger appliances The G4SE offers ultra low consumption to reduce power requirements The G4SE Expander accomplishes this by providing a separate strobe that fits readily behind a Genesis EG4S Series speaker or speaker strobe or Genesis LED EG4 horn strobe or horn strobe attractive low profile design allows a single compact to house three vital notification elements a clear strobe that serves life safety requirements a multi candela strobe that serves MNEC needs and highly intelligible multi tap multi purpose loudspeaker or 3 horn UL C Listed Genesis LED G4SE Strobe Expander offers all advanced features found in the popular Genesis LED line notification appliances including ultra low current draw and cover skins G4SE Strobe Expanders are 100 percent with legacy Genesis appliances on the same circuit G4SE packs two independent strobes and a loudspeaker into one sleek low profile design that is actually slimmer than other single strobe units on the market today Functionally aesthetically the G4SE Strobe Expander continues the LED tradition of excellence quality and value 1 of 4 D A T A S H E E T K85001 0614 to be used for installation purposes Issue 1.1 Catalog u Speakers Strobes Horns Bells and Chimes05 20 21Technology that saves livesfirealarmresources com Strobe Circuit Wiring Genesis LED G4SE is ideal for new and retrofit applications both fire alarm and mass notification signaling is required allowing a speaker and two independent strobes to be installed a single compact footprint the G4SE cuts down on wall clutter reduces the number of boxes that have to be installed This only speeds installation and reduces costs it also makes for neat installation that minimizes the impact on the interior design the protected space Genesis LED G4SE strobe expander has the color and visible from the bottom of the appliance without removing cover The strobe expander comes with amber red blue and lens options G4SE comes in both white and red housing options with or no marking available Prevailing codes require strobes be used where ambient noise conditions exceed specified levels occupants use hearing protection and in areas of public Consult your Authority Having Jurisdiction details Genesis LED strobes including the G4SE exceed UL C requirements within 10 milliseconds over a two period when used with a compatible synchronization source Genesis LED G4SE also has a 20ms pulse width allowing it be used on the same loop and in the same line of sight as the Genesis strobes Configuration G4E Strobe Expanders may be field configured the desired candela output The output setting is visible a small window on the bottom of the device and is by simply sliding the switch until the desired setting in the window Notification appliance strobe circuit in signal shown in the active condition Expander strobe circuit in signal polarity shown the active condition Expander strobe circuit out Notification appliance strobe circuit out Shorting clip Speaker Circuit Wiring Speaker circuit in shields if used must be and free from earth ground except the signal source Speaker circuit out Shorting clip 2 of 4 D A T A S H E E T K85001 0614 to be used for installation purposes Issue 1.1 Output Light Distribution and Mounting LED G4SE Expanders are intended for indoor wall applications only The typical installation to an electrical is shown below It is recommended to mount the electrical at 83 AFF to ensure the strobe is at the correct height in cm Measured UL minimum Electrical box Strobe expander Sheet metal screws 2X with electrical box Notification appliance Shorting clip Horizontal left Horizontal right Vertical bottom Current VDC VFWR Output lens A models lens G models lens B models lens R models mA cd cd cd cd type flash rate wall mount only Size environment Voltage center offset electrical boxes Sources Temperature dry fps flash per second approx h x 5.12 w x 2.33 d 20.32 cm h x 13.0 cm w x 5.92 cm d North American 4 square box at least 1 38 mm deep to 18 AWG 0.75 to 2.50 mm2 F 0 49 C ambient temperature 0 93 relative humidity to 33 VDC 16 to 33 VFWR in 9.9 cm square 2 1 8 deep max between any two devices To determine allowed wire resistance refer to these specifications and the for the synchronized signal source CC Series Signal Modules Booster and Auxiliary Power Supplies Intelligent and Conventional Control Panels to 158 F 40 to 70 C 3 of 4 D A T A S H E E T K85001 0614 to be used for installation purposes Issue 1.1 Information Strobe Expander White ALERT Marking Amber Lens Strobe Expander Red ALERT Marking Amber Lens Strobe Expander White ALERT Marking Red Lens Strobe Expander White ALERT Marking Blue Lens Strobe Expander White ALERT Marking Green Lens Strobe Expander White No Marking Amber Lens Strobe Expander White No Marking Red Lens Strobe Expander White No Marking Blue Lens Strobe Expander White No Marking Green Lens that saves lives us 888.244.9979 Option 4 kidde esfire com kidde fire carrier com is a Carrier brand Town Center Pkwy FL 34202 2021 Carrier Rights Reserved 4 of 4 D A T A S H E E T K85001 0614 to be used for installation purposes Issue 1.1
