Kidde K85001-1026 -- Genesis LED EG4S Series Wall Mount Speakers and Speaker-Strobes

Wall Mount and LED EG4S Series LED EG4S Series speakers and speaker strobes high performance output with a sleek low profile and energy efficient technology that makes them less to install and operate High performance LEDs require power supplies backup power and batteries These appliances are designed with energy efficiency and life in mind feature selectable wattage taps while speaker allow for both wattage and light output levels to be in the field Both settings remain clearly visible even after final installation Speakers are also capable of 25V and 70V and voltage in a single model with a field switch All this flexibility allows devices to be easily to exactly how they needed to perform All Genesis include a DC blocking capacitor to allow electrical of the audio distribution circuit LED EG4S Series uses high efficiency optics combined patented electronics to deliver a highly controlled and focused light distribution pattern in exchange for lower requirements Strobes feature field selectable 15 30,75 110 cd light output with Xenon type strobes Genesis LED EG4S Series offer greatly reduced current draw which provides in longer circuit lengths more devices per circuit smaller gauge and reduced power supply quantities for an installation are also backwards compatible with legacy strobes so no need to replace all your existing devices to upgrade to LED technology In fact EG4S strobes can be mixed on the circuit and used in the same field of view as Xenon based This makes Genesis LED EG4S Series ideal for new and retrofits alike sound output levels provide the flexibility life safety projects demand while the Genesis LED protocol keeps multiple strobes on compatible NAC synchronized to well within NFPA 72 requirements also meet NFPA and UL 520Hz requirements for sleeping making them ideal for new construction or retrofits Series speakers produce crisp clear voice audio output is highly intelligible over large areas In an emergency is critical to life safety Understanding the content of message is as important as knowing there is an emergency is measured in Speech Transmission Index and above 76 is considered excellent EG4S Series deliver audio with an STI of 81 ensuring the message clear is another area where EG4S Series appliances The universal room side wiring plate allows for pre and electrical wiring as well as checking continuity with included diagnostics check bar EG4S Series devices can then easily snapped into place with the confidence of knowing the is correct The innovative under cover diagnostic test points easy access to device circuit testing while mounted 1 of 6 D A T A S H E E T K85001 1026 to be used for installation purposes Issue 1.3 Catalog u Speakers TelephonesTechnology that saves livesfirealarmresources com Features High Fidelity performance with excellent STI Increased sound fidelity and audio intelligibility with STI rating of 81 More than 76 is excellent Low Frequency 520Hz capable Low frequency output meets NFPA standards for constructed commercial sleeping areas High Performance LED Strobe Technology More devices per circuit Ability to use lower gauge wire Longer wire runs Fewer booster power supplies Ultra low device current consumption allows High efficiency optics Selectable 15 30 75 or 110 cd light output LED devices may be mixed with legacy Xenon strobes the same circuit and in the same field of view Field flexibility Speakers are also capable of both 25V and 70V and voltage in a single model with a field selectable switch Speakers feature selectable wattage taps for 1W and 2W to configure sound output levels in the field Low profile Design Ultra slim protrudes about 1.5 from the mounting surface Attractive appearance no visible mounting screws Multiple Marking Options Order in red or white with or without FIRE markings Change markings at any time with replaceable covers Easy to Install Pre install and pre wire with convenient universal room side wiring plate Check electrical continuity on room side wiring plate with included diagnostics check bar Diagnostics port streamlines device circuit testing Fits 2 gang and 4 inch square electrical boxes Optional red and white trim plates available Slide switches for field configuration 12 to 18 AWG in out screw terminals for quick wiring Current draw is the same for all candela output settings Easier for new system design Flexible for future changes in light output needs EG4S Series strobes are UL 1971 listed for use indoors wall mounted public mode notification appliances for the impaired Prevailing codes require strobes to be used ambient noise conditions exceed 105 dBA 87 dBA in where occupants use hearing protection and in areas public accommodation as defined in the Americans with Act is important in order to avoid triggering seizures people with photosensitive epilepsy All Genesis strobes exceed synchronization requirements within 10 milliseconds over a period when used with a synchronization source See specifications table for a list of compatible sources suggested sound pressure level for each signaling zone used alert or alarm signals is a minimum of 15 dB above the aver ambient sound level or 5 dB above the maximum sound level a duration of at least 60 seconds whichever is greater This measured 5 feet 1.5 m above the floor the distance from the signal to the ear will theoretically a 6 dB reduction in the received sound pressure level The effect depends on the acoustic properties of materials in the Doubling the power output of a device e g a speaker from to 2W will increase the sound pressure level by 3dBA Fidelity Sound LED EG4S Series High Fidelity appliances feature 87dB sound output along with a highly intelligible Speech Transmission STI rating of 81 An STI rating above 76 is considered for speech intelligibility They are also effective in areas to high levels of ambient noise appliances are ideal for hotels dormitories and other occupancies that have sleeping areas that require 520Hz In sleeping areas always ensure that the wattage tap of the is set sufficiently high so that the sound pressure reaches least 75 dBA at the pillow appliances are part of an end to end audio system for use in sleeping areas when used in conjunction approved audio hardware and a factory supplied 520 Hz Check the System Compatibility List for other 520 Hz requirements EG4S speakers and speaker strobes mount to the GRSW room side wiring plate The GRSW mounting is included with the device for convenient pre installing and The device can be removed easily from the room side plate by pushing up with a screwdriver The cover can also removed from the device easily with a screwdriver to access light and sound output settings and a diagnostics test port for testing LED EG4S Series speakers and speaker strobes mount any standard two gang and 4 inch square electrical box optional G4T trim rings are available to cover oversized Optional color matched double gang surface boxes also available Cover Device 2 of 6 D A T A S H E E T K85001 1026 to be used for installation purposes Issue 1.3 Box Notification Appliances Plate optional cm cm Plate Screw Appliance cm Clip Mount Box Mount Box ON OF BOX KNOCKOUT 7.21cm 7.34cm 6.35cm 5.97cm OF LENS MINIMUM 80 INCH FINISHED FLOOR Trim Plate cm cm cm Out Out Clip In In 3 of 6 D A
