REVERSING RELAY SYNCHRONIZATION MODULE SERIES for a with 2 and 4 wire i3 detectors with a sounder all i3 sounders on a loop when one all i3 sounders on the loop alarm signal be used with bell alarm alarm relay or outputs a eld selectable switch to both coded and continuous signals i3 detector silencing from the panel or on 12 and 24 volt systems harness and color coded wires connections Speci cations relay synchronization module shall be an i3 Series model number CRRS MODA listed Underwriters Laboratories as a smoke detector The module shall allow all 2 wire and i3 Series detectors equipped with a sounder a loop to sound when one alarms The module provide a switch to toggle between coded mode continuous mode When in coded mode the shall synchronize the i3 sounders on the loop mirror the input signal When in continuous mode module shall synchronize the i3 sounders on the to the ANSI S3.41 temporal coded pattern In coded or continuous modes the module shall sounders to be silenced at the panel The shall operate between 8.5 and 35 VDC and provide 18 AWG stranded tinned conductors to a quick connect harness CRRS MODA reversing relay synchronization enhances the operation of 2 and 4 wire i3 detectors equipped with a sounder Ease module includes a Velcro attachment for easy into the re alarm control panel cabinet quick connect harness and colour coded wires connections module design is exible to accommodate any application The CRRS MODA is with both 2 and 4 wire i3 series detectors over 12V and 24V systems The module be used with either bell alarm alarm relay NAC outputs and its field selectable switch both coded and continuous alarm Inspection meet re alarm requirements the CRRS MODA all i3 sounders on a loop when one alarms the module synchronizes the output of i3 sounders regardless of whether the panel signal is continuous or coded to ensure a alarm signal reserves the right to make changes at any time without notice in prices colours materials components equipment speci cations and models and also to discontinue models TO BE USED FOR INSTALLATION PURPOSES NUMBER Speci cations Voltage Speci cations Temperature Range 0 V V V 2.5 inches 63 mm 2.5 inches 63 mm 1 inch 25 mm System Triggered from Alarm Bell Circuit Operating Current mA Contact Rating A 35 VDC Humidity Range to 85 non condensing Connections AWG stranded tinned 16 long System Triggered from Alarm Relay Contact diagrams represent common wiring methods to the CRRS MODA manual for additional con gurations LISTED signal alarm state POWER LISTED Contact POWER IN OUT IN OUT RA RA IN OUT IN OUT RA RA IN OUT IN OUT RA RA IN OUT IN OUT RA RA Information Number Description relay synchronization module for i3 series smoke detectors TO BE USED FOR INSTALLATION PURPOSES by Interchange Way Ontario L4K 5W3 905 660 4655 905 660 4113 Witmer Industrial Estates Falls NY 14305 Free 888 660 4655 Toll Free 888 660 4113 page http www mircom com Email mail mircom com 5151 1
