Mircom CAT-5208 MH-25 Series Piezoelectric Mini Horns (English)

PIEZOELECTRIC MINI HORNS SERIES High sound output for enhanced audibility over 90 at 10 feet 24VDC push button and red LED to indicate signal circuit on MH S25 versions VDC models with wide listed voltage range DC Non Silenceable only Polarized inputs for compatibility with standard polarity supervision of circuit wiring by an panel Mounts into standard single gang box Flush or surface mounting options Compatible with sensitive detection and circuits Available in red or off white finish Instructions Mini Horn GANG GANG Silenceable Mini Horn The MH 25 Series mini horns are compatible with the and CNSIS 204 Conventional Signal Isolator Modules refer to Cat Sheet 5223 and 5224 MH 25R MH S25WA MH 25 Series mini horns are compact alarm appliances that are ideal for alarm in individual rooms apartments hotels and where attractive appearance and dependable are prime concerns When activated the Series mini horns produce a high sound output over 90 dBA at 10 feet with a minimum current draw 15.5 milliamps at 24 VDC unfiltered on the non models Designed as alert or alarm signal for use with any conventional Fire Alarm panel the MH Series mini horns are available a standard version MH 25 and a Silenceable version MH S25 versions are silenceable mini horns with a push button and a red LED indicate signal circuit when lit The push allows the user to silence the mini horn for a of 10 minutes upon which the mini horn will again until the signal circuit is inactive or the mini is silenced again or the fire alarm panel is reset the fire alarm being reset it takes approximately seconds for the MH S25 Mini Horns to reset MH 25 Series mini horns are designed for easy with convenient mounting to standard single boxes and in out wire leads for fast connection front face plates are ruggedly constructed of impact thermoplastic and are available in fire red or off white to blend with any room decor INFORMATION IS FOR MARKETING PURPOSES ONLY AND NOT INTENDED TO DESCRIBE THE PRODUCTS TECHNICALLY NUMBER MH 25W Voltage Current Sound Level anechoic both and axes 24Vdc fwr mA via FACP V 33 V 24Vdc fwr mA via FACP V 33 V MH S25W Voltage Current Sound Level anechoic both and axes dBA dBA on axis 90 trg on axis 90 ref Level in the indoor installation may vary depending upon the space are intented for dwelling use ONLY does not recommend any changes to the factory applied finish Level in the indoor installation may vary depending upon the space are intented for dwelling use ONLY does not recommend any changes to the factory applied finish temperature 20 60 4 140 A B S Selection Red White 2.2 oz 63g 6 32 screws provided temperature 20 60 4 140 15.5mA STBY ALARM NEXT BELL E L R OF LINE RESISTOR both leads for connection wire run to provide electrical supervision Wiring Diagrams Mini Horn NOT PAINT ALARM DEVICE DIA mm Silenceable Mini Horn NOT PAINT ALARM DEVICE DIA in mm TO OUTPUT TO OUTPUT ALARM INFORMATION IS FOR MARKETING PURPOSES ONLY AND NOT INTENDED TO DESCRIBE THE PRODUCTS TECHNICALLY NEXT BELL E L R OF LINE RESISTOR 5208 2 of 2 Information Mini Piezo Mini Piezo Listings ULC CSFM MEA ULC CSFM MEA Interchange Way Ontario L4K 5W3 905 660 4655 905 660 4113 Witmer Industrial Estates Falls NY 14305 Free 888 660 4655 Toll Free 888 660 4113 www mircom com mail mircom com INFORMATION IS FOR MARKETING PURPOSES AND NOT INTENDED TO DESCRIBE THE PRODUCTS complete and accurate technical information relating performance installation testing and certification refer technical literature This document contains intellectual of Mircom The information is subject to change by without notice Mircom does not represent or warrant or completeness 5208 6
