CONVENTIONAL FIRE ALARM CONTROL UNIT FA 1008KADS to UL 864 9th edition Class B Style B Initiating Circuits which may configured as 4 Class A Style D Circuits up to 24 Class B or 12 Class A Circuits Class A B Style Z Y Indicating Circuits with trouble indicators 1.7 Amps max per Each Indicating Circuit can be configured as or Non Silenceable Audibles be configured as Steady Temporal Code Code or March Time Each Initiating Circuit can be configured as Supervisory Waterflow or Trouble Two LEDs per Initiating circuit one for Trouble one for Status and Indicating Circuits may be disconnected by a DIP switch Configurable Signal Silence Inhibit Auto Signal Two Stage Operation and One Man Test Alarm Verification on Initiating Circuits Subsequent Alarm Supervisory and Trouble Two outputs for 4 wire resettable smoke power 200 mA Max each Auxiliary relay contacts for Common Alarm and Supervisory as well as a Common Relay Each relay contact Form C 28 1 Amp resistive RS 485 Interface for RA 1000 Remote Multiplex for Remote Trouble Indicator Easy configuration via push buttons and DIP on the front panel Amp Power Supply Extensive Transient Protection Modules UDACT 300A Digital Communicator PR 300 Polarity Reversal and City Tie Module FA 1008KADS Fire Alarm Control Unit is microprocessor based unit designed for maximum and easy installation Fully configurable the front panel using the push buttons and DIP it enables the user to configure the system meet their specific requirements FA 1008KADS consists of one MCC 1024 6ADS Chassis in a UB 1024DS back box with a DOX door The MCC 1024 6ADS Main Chassis complete with 8 Class B Style B Initiating which may be configured as 4 Class A Style Circuits It can be expanded up to 24 Class B 12 Class A circuits with the addition of the DM Initiating Circuit Module In addition it comes with 4 Class A B Style Z Y Indicating which are each rated at 1.7 Amps The Chassis also includes a 6 Amp Power Supply powers the system and supplies two 4 wire regulated smoke power supply of 24 VDC maximum each MCC 1024 6ADS also allows for the addition of SGM 1004A Signal Modules or two RM 1008A modules in place of the DM 1008A Initiating Adder Modules Maximum of 3 Adder modules backbox provides space for up to 18 AH Gel batteries reserves the right to make changes at any time without notice in prices colours materials components equipment specifications and models and also to discontinue models TO BE USED FOR INSTALLATION PURPOSES NUMBER Mircom FA 1008KADS is designed as an Microprocessor Based Fire Alarm Unit which is expandable up to 24 display Its modular design suits various applications for applications such as small institutional commercial buildings shopping malls offices public establishments the FA 1008KADS is to meet virtually all requirements The is designed to be easy in its installation operation maintenance This makes the system cost and very reliable for its intended applications built in trim ring 26 x 14.5 x 4.2 Ratings Line Voltage Supply Ratings Indicating Circuits Capability Consumption 60Hz 240V 50 Hz 2A 1A primary Amps max secondary unfiltered 5 Amps maximum AH batteries mA mA Information Alarm Control Unit Modules Modules Annunciators of Line Resistors Based Fire Alarm Control Unit expandable up to 24 display points MCC 1024 6ADS Main Chassis UB 1024DS back box and DOX 1024DS white door Class B Style B or 4 Class A Style D Initiating Circuit Module Class A B Style Z Y Notification Appliance Circuit Module Rated at 1.7 Amps per circuit Relay Circuit Module c w eight Form C relays Rated for 28 VDC 1 Amp max per relay Alarm Communication Transmitter Dialer Module Reversal and City Tie Module Remote LED Annunciator c w 16 Bi Colored LEDs and 16 Trouble LEDS Remote LED Annunciator c w 32 Bi Colored LEDs and 32 Trouble LEDSs LED Annunciator Module c w 48 Bi Coloured LEDs and 48 Trouble LEDs Trouble Indicator Enclosure Houses one module Add suffix for red door Enclosure Houses two modules Add suffix for red door Enclosure Houses three modules Add suffix for red door Resistor Plate Resistor Plate Red TO BE USED FOR INSTALLATION PURPOSES by Interchange Way Ontario L4K 5W3 905 660 4655 905 660 4113 Witmer Industrial Estates Falls NY 14305 Free 888 660 4655 Toll Free 888 660 4113 page http www mircom com Email mail mircom com 5627 0
