Mircom CAT-5660 FA-300 Series Canadian Fire Alarm Control Panels (English)

FIRE ALARM CONTROL UNITS SERIES in eight and twelve zone models with an UDACT Digital Communicator on select panel using CFG 300 configuration tool and programmable upload download capabilities panel is equipped with Class Style circuits which may be configured as Class Style using a Class converter module circuits may be configured as Alarm Alarm Waterflow Alarm Sprinkler Alarm or Non Latching Supervisory and Trouble Only panel is equipped with Class Style circuits which may be configured as Class Style using a Class signal converter module disconnect buttons for both initiating and circuits signals may be configured for Steady Code California Code and March Time Circuits may be configured as Silenceable Non Silenceable for both signals and strobes sync protocols for the following strobe Mircom Amseco System Sensor Faraday and Wheelock contacts for Common Alarm Auxiliary Alarm Common Supervisory and Trouble Signal Silence Inhibit Auto Signal and One Man Walk Test Alarm Supervisory and Trouble Stage operation Interface for Remote LED Annunciators Annunciators and Remote Smart Relay for a Remote Trouble Indicator RTI event history logs comprised of a 200 event log for alarm related events and a 200 event log for all other events i3 Series Smoke Detectors Amp Power Supply modules for additional internal relay circuits City Tie Polarity Reversal trim ring for semi flush mounting FA 300 Series fire alarm control panels of eight and twelve zone models which are with an LED display and an integrated Communicator on select models The Series family also includes remote LED and annunciators as well as remote relay modules FA 300 Series panels are ideal for both new and applications Designed for small to medium institutional and industrial occupancies panels are powerful enough to meet today demands FA 300 Series panels are configurable by keypad using the CFG 300 Configuration Tool onsite programming or by a PC for both onsite remote programming Easy to install and simple operate and configure the FA 300 Series panels the installer to configure the system to meet specific requirements of the FA 300 Series panels are equipped with a Amp power supply 4 wire resetable smoke power 300mA max an interface for a Remote Indicator RTI and an RS 485 interface for LCD annunciators LED annunciators and Relay modules FA 300 Series panels come complete with a white black enclosure durable CAT 30 lock and key space to mount up to 12 AH batteries An optional ring is available for semi flush mounting reserves the right to make changes at any time without notice in prices colours materials components equipment specifications and models and also to discontinue models TO BE USED FOR INSTALLATION PURPOSES NUMBER Circuits FA 300 Series panels are equipped with Class initiating circuits with individual disconnect The initiating circuits may be configured as Style using an ICAC 306 Class adder module Each initiating circuit has LEDs one dual colour Red Amber for Alarm Supervisory and one Trouble LED Amber Circuits FA 300 Series panels are equipped with with Class Style indicating circuits individual disconnect buttons The indicating may be configured as Class Style an OCAC 304 or OCAC 302 Class signal adder module Each indicating circuits has individual trouble LED Amber initiating circuit may be configured for one of following modes of operation audible signals may be configured for Steady Code California Code and March Time Without smoke detector verification Waterflow Alarm Water flow sensors Alarm Sprinkler flow sensors Supervisory Non Latching Supervisory Monitor non latching inpu to a relay circuit for monitoring a trouble an external device of the indicating circuits may be configured for of the following modes of operation Non Silenceable Signal Strobe Non Sileneceable Strobe FA 300 has built in sync protocols for the strobe manufacturers Mircom Amseco Sensor Gentex Faraday and Wheelock Series Protocol FA 300 Series panels have the i3 Series protocol The panels support the two wire i3 Series detectors 2W B 2WT B These i3 series communicate with the FA 300 to provide following status information circuit trouble trouble indicates that loop is broken trouble trouble indicates that there is a fault in the line or line is too noisy the panel cannot communicate the devices device devices on the i3 zone are dirty of sensitivity devices on the i3 zone is out of sensitivity and detect an alarm condition trouble device has detected a freeze condition e g the is below 41 5 available only on 2WT B built in protocol removes the need for the 2W Maintenance Module Communicator FA 300 Series panels are equipped with a integrated UDACT Digital Communicator which for the reporting of events to a monitoring The UDACT Digital Communicator can configured for single or dual line operation and the Security Industry Association SIA and Contact ID protocols The UDACT Digital is configured via the main display and on the main panel addition to its reporting functions the integrated Communicator can be used to to the FA 300 panel from remote computers uploading and downloading of configuration data also allows for the viewing of the event history The FA 300 series panels have two event logs comprised of a 200 event alarm log for related events and a 200 event general log all other events integrated UDACT Digital Communicator can configured for either DACT or UDACT operation DACT mode the Digital Communicator reports alarm trouble and supervisory information UDACT mode the Digital Communicator reports specific information TO BE USED FOR INSTALLATION PURPOSES 5660 2 of 6 Series LED Version Models FA 301 8LDW Eight Zone LED Display Alarm Control Panels FA 301 8LW and FA 301 8LDW are equipped eight Class Style initiating circuits four Class Style indicating circuits 1.7 Amps maximum Total of 5 Amps The is equipped with a built in UDACT Communicator Two ICAC 306 Six Initiating Class Converter Modules may be used for Style wiring of the initiating circuits OCAC 304 Four Indicating Circuit Class Module may be used for Class Style wiring of the indicating circuits The FA 301 8LW FA 301 8LDW are configurable by the keypad the CFG 300 Configuration Tool for onsite or by a PC for both onsite and remote The cabinet will support up to 12 AH The panels can be semi flush mounted the optional FA UNIV TRB trim ring FA 301 12LDW Twelve Zone LED Fire Alarm Control Panels FA 301 12LW and FA 301 12LDW are equipped twelve Class Style initiating circuits four Class Styl
