Mircom CAT-5685 MIX-DH3000 Series Alpha Intelligent Duct Detectors (English)

ALPHA INTELLIGENT DUCT DETECTORS MIX DH3000 SERIES Technology Both Ionization and models listed for velocities between ft min Ionization and Photoelectric models listed for temperature applications supplied with slide in MIX ADD Address Card easy device addressing pending Required front or rear and removing sampling exhaust tubes pending Port Valve allows for aerosol testing without cover removal cover fitted with four captive thumbscrews cover removal trouble indication terminal block for easier wiring red LED on detector head indicates alarm wiring space than competitive models allows easy retrofit in many applications additional drilling wall gaskets on back of enclosure are pre mounting tabs do not require cover to install cover gasket indicates proper cover seal terminal connection screws Series interchangeable UL268 or ionization heads detector head design yields internal filtering additional screens or filters to clean with FX 350 Fire Alarm Control Panels wiring details permanently attached to unit with relay voltages 24VAC or 24VDC terminal block for easier wiring accessories available green pilot and red alarm visual indicators set of 15A form alarm contacts Ionization Duct Detector Photoelectric Duct Detector with Relay MIX DH3000 Series Intelligent Smoke Detectors are the latest analog addressable for early detection of smoke and products of present in air moving through HVAC ducts Commercial Industrial and Residential applications Duct Detectors are designed to prevent the or spread of smoke by air handling fans and blowers Complete systems may shut down via the building fire alarm control FACP in the event of smoke detection MIX DH3000 Series are Low Flow Ionization Photoelectric air duct smoke detectors that capable of sensing smoke in air velocities from to 4,000 feet per minute 0.5 to 20.32 m sec technology can detect smoke at air speed of 100 feet per minute or greater while the same reliable performance to 4,000 per minute MIX DH3000 Series are designed and built meet all local code requirements as well as NFPA and ICC standards regarding HVAC and return duct smoke detectors Output are provided for a remote alarm indicator reserves the right to make changes at any time without notice in prices colours materials components equipment specifications and models and also to discontinue models TO BE USED FOR INSTALLATION PURPOSES MIX DH3100R MIX DH3100 NUMBER Specifications Class Wiring Diagram Class Wiring Diagram Alarm Panel Alarm Panel 1 X 1 X Connections Accessory Wiring Specifications duct smoke detectors shall be Mircom MIX DH3000 Series For ionization detectors the model number is MIX DH3000 photoelectric detectors the model number is MIX DH3100 The detectors shall be listed by Underwriters Laboratories per UL detectors shall operate at air velocities from 100 feet per minute to 4,000 feet per minute and at temperatures of no greater 140 60 indication of alarm and power must be provided on the detector handling unit shut down shall be accommodated via the associated FACP head shall not require additional filters or screens which must be maintained housing shall contain a detector base which will accept photoelectric or ionization detector heads as well as a means detector addressing connections shall be of the screw type a minimum of 6 screw 12 to 22 AWG compatible Terminals shall be for remote alarm indication All wiring must comply with local codes and regulations method of testing the alarm function with a magnet must be provided method of smoke testing the detector without removing the cover must be provided unit remote accessory and common function connection designations must be permanently affixed to the unit and sampling exhaust tube installation or removal must not require the use of tools and exhaust tubes shall be capable of removal installation from the front and or rear of the detector for inspection TO BE USED FOR INSTALLATION PURPOSES 5685 2 of 4 Specifications Class Wiring Diagram Class Wiring Diagram Alarm Panel Alarm Panel 1 X 1 X OR BUTTON SWITCH LED ALARM AND OR LED Connections Accessory Wiring SERIES SMOKE DETECTOR ACCESSORIES Specifications duct smoke detectors shall be Mircom MIX DH3000 Series For ionization detectors the model number is MIX 3000R For detectors the model number is MIX 3100R The detectors shall be listed by Underwriters Laboratories per UL 268A detectors shall operate at air velocities from 100 feet per minute to 4,000 feet per minute and at temperatures of no greater 140 60 indication of alarm and power must be provided on the detector front manual relay test switch located on the front of the device shall be provided head shall not require additional filters or screens which must be maintained and shall include both a standby and visual indication housing shall contain a detector base which will accept photoelectric or ionization detector heads as well as a means detector addressing connections shall be of the screw type a minimum of 6 screw 12 to 22 AWG compatible Terminals shall be for remote alarm indication All wiring must comply with local codes and regulations method of smoke testing the detector without removing the cover must be provided unit remote accessory and common function connection designations must be permanently affixed to the unit and sampling exhaust tube installation or removal must not require the use of tools and exhaust tubes shall be capable of removal installation from the front and or rear of the detector for inspection TO BE USED FOR INSTALLATION PURPOSES 5685 3 of 4 Accessories MS RA and MRTS KAPR remote accessories are designed to be used with Duct Smoke Detectors to provide visual indication on the detector as well as test reset functions The MS RA provides an LED indicator while the MRTS is equipped with LEDs and a test reset switch Enabling the switch on MRTS KAPR provides a local alarm indication on the duct detector but not at the alarm control panel Both models are constructed of attractive durable brushed steel and mount on a standard single gang electrical backbox
