ADVANCED PROTOCOL INTELLIGENT MANUAL STATIONS MS 700AP SERIES Key resettable Permanently attached intelligent addressable Two stage model is equipped with an module that provides two addresses for and 2nd stage operation Rotary switches for direct dial entry of address unit can have address set for 01 159 for Protocol mode and 01 99 for CLIP mode High gloss red enamel finish Plastic break rod Meets ADA 5 lb maximum manual force Mounts on standard single gang box Mircom surface metal backbox or BB 700WP proof backbox Bilingual versions MS 710AP Dual Action Intelligent Manual Station is by pushing the bar labelled BAR and pulling down the handle marked HANDLE MS 710AP is reset by opening the station with the placing the handle in the normal upright position re locking the station The MS 702AP two stage also provides a key switch which is accessible the handle has been pulled Operation of the key will initiate the 2nd stage of a two stage alarm system manual station shall be Mircom MS 710AP instructions shall be in raised English and lettering and the unit shall be constructed of quality die cast metal and finished in red enamel to provide quick identification Pulling the handle initiate immediate operation of the intelligent In addition those stations installed in a two system shall come equipped with an internal switch designed to operate the 2nd stage alarm circuit All manual fire alarm stations shall installed to comply with the Canadian Electrical CSA 22.1 and CAN ULC S524 01 Standard for of Fire Alarm Systems Final acceptance subject to the local authority having jurisdiction MS 700AP Series Advanced Protocol Manual Stations are made of a high quality metal and include a permanently attached module These intelligent manual stations a pair of rotary decimal switches which allow for digit address setting Pulling the handle initiates operation of the intelligent module manual stations are available with CAT 30 keys mount on a standard single gang backbox Mircom BB 700 interior surface metal backbox or BB weather proof backbox MS 710AP is a dual action manual station with a reset The MS 702AP is a single action manual that includes an additional General Alarm G A switch For safety reasons the G A switch is only after the handle has been pulled A special is supplied with each unit Advanced Protocol AP devices use a high communication protocol that greatly increases speed of communication between the intelligent Mircom Advanced Protocol uses a superior polling method as well as an interrupt feature provide for a faster response to an alarm condition addition the Advanced Protocol allows for greater capacity with support for up to 318 devices per circuit The AP devices are backwards compatible operate in CLIP mode for legacy system applications reserves the right to make changes at any time without notice in prices colours materials components equipment specifications and models and also to discontinue models TO BE USED FOR INSTALLATION PURPOSES NUMBER Operating Voltage Alarm Current 24V Operating Current 24V Mount Backboxes H x 3.56 W x 2.9 D VDC H x 3.56 W x 2.56 D VDC mA Surface Mount H x 3.6 W x 2.0 D Weatherproof Mount Backbox H x 3.6 W x 2.2 D Diagram NEXT STATION OR OF LINE DEVICE Diagram OF MANUAL STATION HOLE STATION GANG BOX BLACK RED HOLE Information Protocol Intelligent Key Resettable Dual Action Manual Station Bilingual Protocol Intelligent Key Resettable Two Stage Manual Station Bilingual 700 Interior Surface Mount Backbox Red Finish 700 Weatherproof Surface Mount Backbox Red Finish TO BE USED FOR INSTALLATION PURPOSES by Interchange Way Ontario L4K 5W3 905 660 4655 905 660 4113 Witmer Industrial Estates Falls NY 14305 Free 888 660 4655 Toll Free 888 660 4113 page http www mircom com Email mail mircom com 5956 0
