FIRE ALARM MANUAL STATIONS SERIES High quality extruded aluminum Attractive Low Profile Design Built in intelligent addressable module with Mircom Pulling the handle initiates the operation of the intelligent Address is set by the MIX 4090 hand held device Key switch provided for two 2 stage version Standard Single Gang Mount Plastic Rod or Break glass Optional MS 400MP U Series Fire Alarm Manual Stations manual fire alarm activation These pull stations are as one stage or two stage stations On the two stage a key switch allows the activation of the stage two with FX 400 series and FleX Net MP Fire Alarm Panels MS 400MP Manual stations are constructed of high extruded aluminum and finished in red An abrasion label with large raised letters provides clear legible station has a permanently attached MP Mircom addressable module is done using the MIX 4090 Device programmer model MS 402MP two stage is similar to the MS 401MP stage except it contains an additional General Alarm N O switch For safety reasons the G A switch is only after the handle has been pulled A special key is with each unit model MS 407MP U is a single stage manual station an additional N C switch Suffix indicates a USA version the alarm on the station handle will release the internal switch trigger the intelligent addressable module the stage two alarm MS 402MP only MS 402MP U two stage version also provides a key which is accessible after the handle has been pulled of the key switch will initiate the 2nd stage of a two alarm signaling system the Manual Station is accomplished by inserting a 1 8 screwdriver the front The handle once pulled will remain open and be reset without utilizing the screwdriver Resetting the station does not cancel the alarm at the manual fire alarm stations shall be installed as per the requirements outlined in the UL ULC codes as well all other applicable national or local codes TO BE USED FOR INSTALLATION PURPOSES INFORMATION IS FOR MARKETING PURPOSES ONLY AND INTENDED TO DESCRIBE THE PRODUCTS TECHNICALLY NUMBER Operating Voltage Alarm Current Alarm Current H x 3.3 W x 0.762 D VDC mA mA Diagram Diagram STATION GANG BOX NEXT STATION OR OF LINE DEVICE FUNCTION NORMALLY SWITCH ONLY BLACK RED Information Single Stage Manual Station ULC Two Stage Manual Station ULC Single Stage Manual Station with additional N C switch ULC Single Stage Manual Station UL Single Stage Manual Station with additional N C switch UL Device Programming Tool Plastic Rod Break glass Interchange Way Ontario L4K 5W3 905 660 4655 905 660 4113 Witmer Industrial Estates Falls NY 14305 Free 888 660 4655 Toll Free 888 660 4113 INFORMATION IS FOR MARKETING PURPOSES AND NOT TO DESCRIBE THE TECHNICALLY complete and accurate installation testing and certification refer to technical This document contains intellectual property of Mircom information is subject to change by Mircom without notice does not represent or warrant correctness or completeness relating 5961 0
