INX 10AC Booster Chassis Instructions to LT 899 INX 10A Manual Mounting Locations INX 10AC is the same as the INX 10A except for how it is installed The INX 10AC is mounted on a chassis The mounts into backboxes BB 5008 or BB 5014 instead of it own enclosure The INX 10AC can be wired into an loop SLC and provides additional power 10A for signalling circuits NACs notification appliance circuits chassis is mounted using twelve 6 HEX nuts onto the backbox studs see figure below Addressable Booster Chassis twelve black circles represent mounting studs 6 HEX nuts provided to secure to backbox or BB 5014 Board twelve black circles represent mounting studs 6 HEX nuts provided to secure chassis to BB 5008 or BB 5014 Refer to LT 899 INX 10A Installation Operation Manual for all INX 10AC wiring and set up information Aug 2011 Page 1 of 1
