Notification 29 Candela Hazardous Location certified strobes have been designed for use in poten explosive gas and dust atmospheres and harsh environ conditions The glass reinforced polyester enclosures suitable for use offshore or onshore where light weight with corrosion resistance is required strobe housing is manufactured completely from a U V glass reinforced polyester Stainless steel screws and bracket are incorporated ensuring a totally corrosion product can be painted to customer specification and supplied identification labels Unit I Div 2 Groups C D I Zones 1 2 AExd IIB T5 Hazardous locations Ordinary locations Visual Signal Device UL Listed for USA and Canada California State Fire Marshal CSFM Listed ATEX approved NEMA 4x 6 IP66 and IP67 Certified temperature to 158 to Corrosion resistant GRP Optional stainless steel backstrap Various lens colors Optional lens guard Available as a status light Xenon candela wire monitored connection VDC 110 and 240 VAC and Engineers Specifications for hazardous locations and harsh environments shall be UL and cUL listed for Class I Division 2 Groups and Class I Zones 1 2 AExd IIB T5 applications and shall be listed under UL Standard 1638 for Indoor Outdoor The strobe appliances shall be constructed of lightweight UV stable glass reinforced polyester shall be corrosion and shall meet NEMA 4x NEMA 6 IP 66 IP 67 environmental requirements over a temperature range of to 158 55 to 70 strobe shall be rated to flash at 1 Hz with 29 candela per flash Rated current draw shall not exceed 320 mA at 24 The strobe shall be capable of direct surface mounting in any direction Due to continuous development of our products specifications and offerings are subject to change without notice in accordance Cooper Wheelock standard terms and conditions DIMENSIONS IN MIL I Div 2 Groups C D I Zones 1 2 AExd IIB T5 Hazardous locations Listing No E187894 Ordinary locations Visual Signal Device State Fire Marshal CSFM Listed listing No S8128 approved EExd IIB T5 T6 No 99 ATEX 2195X EN50014 and EN50018 Glass reinforced polyester GRP Glass Screws Backstrap Stainless steel 316 black or painted to customer specification UL Listed for USA and Canada to Consumption mA NOTE The Cd figures are for a clear lens 1Hz flash rate Hz Current Cd Energy Temperature Protection Unit lb 2.5Kg to 158 to 70 hazardous to 131 to 55 ordinary 4x 6 IP66 IP67 x 14AWG Label optional x 1 2 NPT strobe may be combined with a sounder to a visual audible alarm COLORED LENSES Multiplying photometric data has been verified by BSI report is available if required Options following code is designed to help in the selection of the correct unit Build up the reference number by inserting the code for component into the appropriate box Lens Color Continuity Other Options Voltage Certification UL UL Ordinary location UW Voltage 24V d c 110V a c 240V a c Color Red Blue Green Amber Yellow Clear 06 Rate flash rates please Guard None Yes Label None Yes Please specify Option Blanking Plug None Fixing Mounting D Code Finish Natural Black Red Blue Yellow Grey White Special Finish Please specify Code Number Models XB11UL02406RNBNNNR 109201 001 Strobe Red lens 29 candela 24 VDC Red Finish XB11UL02406CNBNNNR 109201 002 Strobe Clear lens 29 candela 24 VDC Red Finish XB11UL02406RNBNNNN 109201 003 Strobe Red lens 29 candela 24 VDC Black Finish XB11UL11006ANBNNNR 109201 007 Strobe Amber lens 20 candela 110VAC Red Finish XB11UL11006RNBNNNR 109201 008 Strobe Red lens 29 candela 110VAC Red Finish ENCOURAGE AND SUPPORT NICET CERTIFICATION YEAR WARRANTY 02 08 Location Branchport Ave Branch NJ 07740 800 631 2148 732 222 8707 Location Commerce Ct FL 34243 941 487 2300 941 487 2389 Notification is Location 877 459 7726 703 294 6560
