Fire Sentry FS24X Flame Detectors QuadBand Triple IR and Flame Detectors Sentry FS24X Patented WideBand IR Technology Patented Electronic Frequency Analysis Visible Sensor for optimum false alarm rejection Selectable detection sensitivities Field of View 110 full 100 cone of vision full 100 cone of vision model also Dual microprocessors for reliable performance Real time clock for accurate time dating events FirePic pre fire event data storage Event log with date and time stamp RS 485 ModBus communication Non Isolated 4 20 mA Analog output sink Alarm Fault and Fire Verification relays Automatic optical path and electronic source Widest operating temperature range Patented Electronics Module for protection with easy plug in and field installation Two NPT OR 25mm conduit entries Low power consumption High RFI and EMI immunity FM ATEX CE mark approvals Meets SIL 2 requirements Detects hydrocarbon and non hydrocarbon fires in all environmental conditions User selectable outputs Optimal false alarm rejection for all conditions Minimal maintenance for trouble free PC software and Interface Module FSIM for diagnostics real time graphics RTGs downloading of FirePics and event log Suitable for a wide variety of applications Easy electronics module replacement Test lamps for manual testing Sentry FS24X is a quantum leap in and fire detection with its software and detection Fire Sentry FS24X is the latest generation high technology Multi Spectrum IR IR IR IR Visible Fire and Flame Detector which is part of our FSX of advanced technology Electro Optical fire detectors Using our WideBand IR WideBand 4.3 micron IR and Visible detection the Fire Sentry FS24X is a quantum leap in flame and fire detection software algorithms and dual microprocessors ensure that the Sentry FS24X has the highest fire detection performance combined with false alarm rejection Refineries and Oil Production Facilities Off Shore Platforms Turbine Compressor Enclosures Oil Gas Pipelines and Pumping Stations LNG LPG Loading Unloading Facilities Natural Gas and CNG Plants Ethanol Methanol and IPA Production and Storage Crude Oil and Gasoline Storage and Tank Farms Aircraft Hangars Hydrogen Plants and Storage Paint Solvent Storage Chemical Production Storage and Loading Facilities Power Plants Sentry Corporation Patents Sentry FS24X WideBand IR Infrared technology using high speed solid state Quantum allows detection of all types of fires hydrocarbon and non hydrocarbon all weather conditions If the detector signal is blocked by ordinary window the patented WideBand IR sensors will still alarm to the fire but at a sensitivity and slower response time microprocessors provide a high level of fail safe operation combined fast and reliable performance The Master Microprocessor performs high digital sampling and signal processing calculations while the slave handles various sensor data performs communications self and provides interface versatility and additional memory for storing Log and FirePic data Fire Sentry FSX family of detectors feature our patented FirePic data and information retrieval facility FirePic records pre fire data which be recovered from the Detector non volatile flash memory for post fire and postulation of the fire cause Additionally unique Real Time RTG allows viewing of the data which the Detector actually sees combination of outputs makes the Fire Sentry FS24X a truly versatile detector today demanding industrial requirements Fire Sentry FS24X detector has a detection range greater than 200 feet High Sensitivity setting for the detection of a one square foot Heptane fire and has a cone of vision far greater in volumetric coverage than other Multi Spectrum IR Detector This means fewer Detectors can be used compared to other manufacturers Detectors Sentry Corporation Patents Analytics Lines of Business detection from standalone units to engineered multi point systems offering cost effective regulatory Applications parking structures chillers mechanical rooms office shopping centers swimming pools golf courses schools and universities commercial buildings Sieger and Manning gas systems with advanced infrared and open path technologies Applications oil and gas cold storage water wastewater treatment chemicals engine rooms plastics and fibers agriculture printing and industrial or multi gas Lumidor and other detectors with compact designs ranging from alarm only units to advanced configurable and serviceable Applications underground utility and electricity ducts boiler rooms post fire sites sewers industrial plants industrial hygiene first teams remote fleets out more Honeywell Analytics Analytics Inc Barclay Blvd IL 60069 847.955.8200 800.538.0363 847.955.8210 La Palma Avenue Linda CA 92887 714.694.2700 714.694.2701 Services Tech Government complete portfolio of gas and chemical instrumentation including spectroscopy MST with no cross to Chemcassette paper solutions MDA Scientific offering down to parts per billion Applications semiconductor manufacturing and nanotechnology aerospace propulsion and safety specialty chemicals industry research emergency response Services global network includes service and Systems teams Emergency call out service contracts on off site repair training and commissioning Complete range of spares consumables and accessories Middle East Africa Safety Distribution AG 11a Uster 41 0 44.943.4300 41 0 44.943.4398 Pacific Analytics Asia Pacific Kolon Science Valley 1 Guro Dong Guro Gu 152 050 82 0 2.2025.0307 82 0 2.2025.0329 Note every effort has been made to ensure accuracy in this publication no can be accepted for errors or omissions Data may change as as legislation and you are strongly advised to obtain copies of the most issued regulations standards and guidelines This publication is not to form the basis of a contract 2 12 2012 Honeywell Analytics Sentry Corporation is now part of Honeywell Analytics As we begin to fully our companies you might notice some small changes This integration about bringing together two of the best in life safety We are focused on putting customers first and making the right decisions to guarantee Honeywell continues to remain the experts in fire and gas safety
