STROBE WARNING LIGHT Locations Weatherproof Range listed strobes have been designed for use potentially explosive atmospheres and harsh conditions The enclosures are suitable use offshore or onshore where light weight with corrosion resistance is required housing is manufactured from a U V stable glass polyester with the lens manufactured from U V stable polycarbonate Stainless steel screws are ensuring a totally corrosion free product model XB16 contains supervisory diode and four leads for fire alarm applications This strobe also available UL 1971 ADA listed for hearing applications can be painted to customer specification and with identification labels UL listed for USA and Canada Hazardous locations for USA and Canada I Div 2 Groups A B C D II Div 2 Groups F G 1971 compliant version available Ordinary locations Visual Signal Device Rating model dependent Contact sales office information CSFM approved NEMA 4x and 6 IP66 67 Certified temperature to 158 to 70 Pipe mount with NPT entry Corrosion free GRP enclosure 580,000 peak candlepower Polycarbonate lens various colors available 4 wire diode monitored board Optional relay initiate Optional lens guard to UL standard or regulated voltage 1971 version available with clear lens only Ltd Colliery Road Nottingham NG16 6JF UK North Suite 1005 Houston Texas 77041 USA 44 0 1773 864100 44 0 1773 582800 1 713 937 9772 1 713 937 9773 International 5829 West Sam Houston Parkway Norway Auglaendsmyraa 6 Stavanger Norge 47 913 92 289 47 914 46 030 Enq Fax 44 0 1773 582830 Sales Orders Fax 44 0 1773 582832 sales medc com Web www medc com RANGE with optional guard fitted dimensions in inches and millimeters I Div 2 Groups A B C D II Div 2 Groups F G UL Listed for USA and Canada Hazardous locations for USA and Canada UL1604 listing No E251 185 Ordinary locations Visual Signal Device UL1638 listing No E251185 Hazardous locations for hearing impaired UL1971 listing No E251185 Glass reinforced polyester U V stable polycarbonate screws stainless steel 316 black or painted to customer specification d c 48V d c 120 230 240 254V a c to UL regulated voltage output 24Vdc 120Vac to 158 to 70 Energy 10 Joules life x 106 flashes 4x 6 IP66 IP67 DC 1 x NPT pipe mount Contact MEDC if NPT is x 14AWG label option ratings candlepower Cd 285 at 60 f p m candlepower 580,000 Peak candlepower is the maximum light intensity generated by 1971 On axis output 15 Cd factor for colored lenses Initiate 24V dc relay initiate only AC flashing light during its light pulse Requirements following code is designed to help in the selection of the correct unit Build up the reference number by inserting the for each component into the appropriate box Model Certification XB16 Color Finish Certification UL UL ordinary locations UL 1971 Voltage 24V d c 48V d c 110V a c 120V a c 230V a c 240V a c 254Va c Flashrate Code 60 fpm 80 fpm 120 fpm Color Red Blue Green Amber Yellow Clear UL 1971 version available with clear lens only Option Tag label Duty label Relay initiate R None Suitable for 24V dc supplies only Guard Yes None Finish Natural Black Red Blue Yellow Green White Special Finish the above specifications dimensions weights and tolerances are nominal typical and MEDC reserve right to vary all data without prior notice No liability is accepted for any consequence of use
