12 Clintonville Road CT 06472 484 7161 fax 203 484 7118 2W 4.7K ELR Resistor for VCE 4 DCM 4 Revision A 3 22 96 ECN 96 114 4.7K ELR Resistor Notice for VCM 4 VCE 4 and DCM 4 to higher power dissipation at the 70.7 volt audio level the 2 watt 4.7K end of line resistors supplied with AA 100 Audio Amplifier must be used in place of the resistors supplied with the VCM 4 Voice Control the VCE 4 Voice Control Expander and the DCM 4 Dual Channel Module 50473 A 3 22 96 ECN 96 114 1 of 1
