DN 6135 B C 119 Control Systems Series Telephone Stations and Telephone Accessories Emergency Telephone Stations provide a reliable of communication for firefighters and other personnel Heavy duty construction Keylock or thumb latch Push to talk switch on telephone handset Doors fit either recessed or surface enclosures Red baked enamel finish Armored cable or standard telephone coiled cord Available with or without a door feature Master station connection LED indicator feature a locked door design with either a break or non break glass feature When a locked door is not an optional thumb catch allows for fast safe entry the housing telephone handsets are available with either standard cord or a durable security type armored cable hook configuration consists of two Form C switches which a variety of wiring uses The handset rests on a hand chrome cradle which actuates the switch mechanism recessed or surface enclosures may be used with these Telephone Stations If a recessed enclosure is the telephone assembly must be a model designed for enclosures The same is true of surface enclosures Listings and Approvals some cases certain modules or applications may not be by certain approval agencies or listing may be in pro Consult factory for latest listing status UL S635 ULC CS118 CS733 CSFM 7300 0028 0193 MEA 82 98 E AFAWS TELA City of Chicago approved Class 1 Class 2 City of Denver approved doors on surface mount models with Keylock left Latch Right closures 09 03 2010 Page 1 of 2 Product Line Information front door backbox and telephone assembly for AFAWS telephone stations must be ordered separately AND HOOKSWITCH ASSEMBLIES Telephone with Coiled Cord Assembly Telephone Armored Cord Assembly STATION ENCLOSURES Backbox 381.0mm H x 8 3 8 212.85mm W x 3 3 8 85.73mm D Latch Door for Surface Mount 385.60mm H x 8 9 16 217.45mm W Latch Door for Recessed Mount 411.00mm H x 9 9 16 242.85mm W Keylock Door for Surface Mount 385.60mm H x 8 9 16 217.45mm W Keylock Door for Recessed Mount 411.00mm H x 9 9 16 242.85mm W Breakglass Insert a tempered glass plate a hammer attached to a and a screw to attach the hammer to the trim ring RECEPTACLES Fireman Phone Jack is semi flush mounted with a box box is not furnished with The receptacle has a single jack mounted on an attractive sin stainless steel plate Color wires 6 inches long are prewired the jack to enable fast and accurate wir to the system TELEPHONE CABINETS Storage Cabinet for 6 FHS Fireman handsets mounting Storage Cabinet for 6 FHS Fireman handsets sur mounted DIMENSIONS Below Mount Mount 82.6mm 432mm 340mm 465mm 371mm 82.6mm 432mm 340mm 440mm 346mm FIREMAN TELEPHONE HANDSET Fireman Handset handset comes with a cord The attached plug Fireman Phone Jack FPJ allowing firefighters make direct communication a central control area is a registered trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 6135 B 09 03 2010
