Notifier BB-55 Installation Instructions

File Preview
File Preview
Click below to download for free

File Data

Name notifier-bb-55-installation-instructions-3128075694.pdf
Type PDF
Size 939.41 KB

Text Preview

Installing the Series Cabinet Installation Document 50295 Rev A P N 50295 A 08 30 95 ECN 95 250 Rev A Series minimum Series Cabinet BB 55 Series cabinets consist of a cabinet with lockable door that is hinged on the bottom to down for access to the batteries are designed to be mounted a minimum of inches below the CAB 3 Series Cabinets both cabinets are surface mounted the in the bottom right corner of the CAB 3 will line up directly above the knockout in top right corner of the BB 55 Series cabinet BB 55 Series cabinet should be mounted in a dry vibration free area using the six holes dimensions on the adjacent drawings are shown inches The BB Series cabinets have 0.875 knock which accept standard conduit Side door
