Notifier EQ Cabinet ONYX Series Equipment Bacboxes with Ventilated Locking Doors

EQ Cabinet Series Equipment Backboxes Ventilated Locking Doors Series cabinets provide an effective solution for applica that require distributed components such as power sup amplifiers and multiple I O modules The EQ Series superior ventilation for devices such as amplifiers and power supplies ample room for wire or fiber optic media each row and a space efficient package that allows the consolidation of multiple system components in a single cabinets use a perforated blank door for enhanced and do not support the mounting of backbox dress plates Therefore these cabinets are not appro for equipment that would be normally accessed by a operator such as control equipment annunciators or microphones cabinets share the same external dimensions as the famil CAB 4 Series cabinets EQ Series cabinets differ in that do not include a separate battery row See illustrations for examples of EQ cabinet row spacing Equipment cabinets are fabricated from 16 gauge steel cabinet assembly consists of two basic parts a back and a locking door Cabinets are available in black and The key locked door is provided with a pin type hinge two and the necessary hardware to mount the door to the The backbox has been engineered to provide ease of entry the installer Knockouts are positioned at numerous to aid the installer in bringing a conduit into the with a minimum of hardship Right or left hand hinges selectable in the field Door 180 Cabinets are arranged in 3 standard sizes B two tiers D four tiers See Ordering Information Trim ring options are available for semi flush mounting Compatible for Use in Series Cabinets DAA2 Series Amplifiers DAX Series Amplifiers DS DB Digital Series Distribution Board DS AMP Digital Series Amplifier DAA 50 Series Amplifiers DAA 75 Series Amplifiers AA 30 E Audio Amplifiers AA 100 E Audio Amplifiers AA 120 E Audio Amplifiers ACPS 610 E Power Supply AMPS 24 E Power Supply HPFF8CM E Power Supply HPFF12CM E Power Supply XP6 C Modules Devices XP6 MA Modules XP6 R Modules XP10 MA Modules Listings and Approvals listings and approvals below apply to the EQ cabinet In cases certain modules or applications may not be listed certain approval agencies or listing may be process Con factory for latest listing status UL Listed S635 ULC Listed S635 CSFM 7165 0028 0243 7165 0028 0224 FDNY COA 6121 NFS2 640 COA 6114 NFS2 3030 Information complete cabinet assembly consists of a door a backbox an optional semi flush trim ring For each cabinet order one EQDR door and one EQBB backbox optional trim ring is an attractive style metal ring SIZE CABINET TWO TIERS Door assembly vented door two tiers black For order EQDR B4R Backbox assembly two tiers black For red order Semi flush mount trim ring two tiers 03 19 2013 Page 1 of 4 SIZE CABINET THREE TIERS Door assembly vented door three tiers black For order EQDR C4R Backbox assembly three tiers black For red EQBB C4R Semi flush mount trim ring three tiers SIZE CABINET FOUR TIERS Door assembly vented door four tiers black For order EQDR D4R Backbox assembly four tiers black For red order Semi flush mount trim ring four tiers DRAWINGS AND FEATURES 61.28 60.96 40.64 knockout 1.375 3.49 1.750 4.45 dia dia 49.53 Box lower knockouts 0.875 2.22 1.125 2.86 2 of 4 DN 60229 D 03 19 2013 61.28 60.96 40.64 knockout 1.375 3.49 1.750 4.45 dia dia 49.53 Box lower knockouts 0.875 2.22 1.125 2.86 knockout 1.375 3.49 1.750 4.45 61.28 60.96 40.64 dia dia 49.53 lower knockouts 0.875 2.22 1.125 2.86 03 19 2013 Page 3 of 4 5.72 Box Hole View of Backbox knockout 1.375 3.49 1.750 4.45 lower knockouts 0.875 2.22 1.125 2.86 View of Backbox is a registered trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 4 of 4 DN 60229 D 03 19 2013
