SpectrAlert Advance Low Frequency Sounder Strobes SpectrAlert Advance series offers the most versatile easy to use line of low frequency sounder and low fre sounder strobes in the industry With white and red housings dual listed for wall and ceiling mounting Advance can meet virtually any application the entire SpectrAlert Advance product line all mount low sounder and low frequency sounder strobes a variety of features that increase their application ver while simplifying installation All devices feature plug in with minimal intrusion into the black box making fast and foolproof while virtually eliminating costly time consuming ground faults further simplify installation and protect devices from con damage SpectrAlert Advance use a universal mount plate with an onboard shorting spring so installers can test continuity before the device is installed can also easily adapt devices to suit a wide range of requirements using field selectable candela set automatic selection of 12 or 24 volt operation and a switch for low frequency sounder tones Plug in design with minimal intrusion into the back box Tamper resistant construction Field selectable candela settings on wall units 135 150 and 185 Rotary switch for low frequency sounder tone Universal mounting plate for wall units Mounting plate shorting spring checks wiring continuity device installation Electrically compatible with legacy SpectrAlert Advance Compatible with MDL3 sync module Listed for ceiling or wall mounting Specifications Advance low frequency sounder and low fre sounder strobes shall mount to a standard 4x4x1 1 2 box 4 inch octagon back box or double gang box Two products shall also mount to a single gang 2x4x1 7 8 box A universal mounting plate shall be used for mount products The notification appliance circuit wiring shall ter at the universal mounting plate Also SpectrAlert products when used with the Sync Module shall be powered from a non coded notification circuit output and shall operate on a nominal 12 or volts When used with the Sync Module 12 volt notification appliance circuit outputs shall operate 8.5 and 17.5 volts 24 volt rated notification appliance outputs shall operate between 16.5 and 33 volts Indoor Advance products shall operate between 32 and degrees Fahrenheit from a regulated DC or full wave recti unfiltered power supply Low Frequency Sounder strobes Visual Equipment have field selectable candela settings including 135 150 and 185 FREQUENCY SOUNDER low frequency sounder and the Sync MDL3 accessory if used shall be powered from a notification circuit output and shall operate on a nominal 12 or volts includes fire alarm panels with built in sync When with the Sync MDL3 12 volt rated notification circuit outputs shall operate between 8.5 and 17.5 24 volt rated notification appliance circuit outputs shall between 16.5 to 33 volts If the notification appliances not UL 9th edition listed with the corresponding panel or supply being used then refer to the compatibility listing the panel to determine maximum devices on a circuit The frequency sounder has an option to switch between tem three pattern non temporal continuous pattern and supply The low frequency sounder shall operate on a or non coded power supply FREQUENCY SOUNDER STROBE COMBINATION low frequency sounder strobe shall be approved for fire service The low frequency sounder strobe shall be as a primary signaling notification appliance and comply the Americans with Disabilities Act requirements for visi signaling appliances flashing at 1 Hz over the strobe operating voltage range The strobe light shall consist of xenon flash tube and associated lens reflector system The shall have an option to switch between a temporal pattern and a non temporal continuous pattern These are set by a multiple position switch The low fre sounder on low frequency sounder strobe models shall on a non coded power supply 5 21 2014 Page 1 of 4 MODULE module shall synchronize SpectrAlert strobes at 1 Hz and frequency sounder at temporal three Also while operating strobes the module shall silence the low frequency on low frequency sounder strobe models over a sin pair of wires The module shall mount to a 1 11 16x4 11 back box The module shall also control two Y Class B circuits or one Style Z Class A circuit The shall synchronize multiple zones Daisy chaining two more synchronization modules together will synchronize all zones they control The module shall not operate on a power supply Specifications Operating Temperature 32 to 120 0 to Range 10 93 non condensing Flash Rate 1 flash per second Voltage Low Frequency Sounder Regulated 12 or regulated 24 DC FWR Current Draw MAXIMUM STROBE CURRENT DRAW MA RMS Voltage Range Low Frequency Sounder Strobe 24 VDC FWR Voltage Range 8 to 17.5V 12V nominal or 16 to V 24 V nominal Voltage Range MDL3 Sync Module 8.5 to 17.5V nominal or 16.5 to 33 V 24 V nominal Terminal Wire Gauge 12 to 18 AWG Dimensions including lens 6.4 inches L x 4.7 W x 2.5 inches D 162mm L x 119mm W x 64mm D Dimensions 5.6 inches L x 4.7 inches W x 1.3 D 142mm L x 119mm W x 33mm D Frequency Sounder Strobe with Surface Mount Back Dimensions SBBR SBBW 6.4 inches L x 4.7 inches x 4.3 inches D 162mm L x 120mm X x 108mm D Frequency Sounder with Surface Mount Back Box SBBR SBBW 5.7 inches L x 4.8 inches W x 3 D 145mm L x 120mm X x 76mm D Volts Volts Candela MAXIMUM LOW FREQUENCY CURRENT DRA MA RMS Volts Volts Pattern MAXIMUM CURRENT DRAW MA RMS 2 WIRE LOW FREQUENCY SOUNDER STROBE HIGH CANDELA RANGE 135 185 Volts Volts Input 150 177 185 Input 150 177 185 292 362 344 417 2 of 4 DN 60804 A 5 21 2014 Frequency Sounder Tones and Sound Output Data FREQUENCY SOUNDER AND LOW FREQUENCY SOUNDER STROBE OUTPUT DBA Nominal FWR DC FWR DC Sounder ratings provided are for continuous voltage as provided by the NAC 80 Listings and Approvals listings and approvals below apply to the SpectrAlert series In some cases certain modules or applica may not be listed by certain approval agencies or listing be process Consult factory for latest listing status UL Listed S4011 S5512 CSFM 7135 1653 0223 HR LF HW LF 7125 1653 0224 P2WH LF FM 3047563 Information 2 wire wall low frequency sounder strobe High cd wall low frequency sounder strobe High cd low frequency sounder red low frequency sounder white back box skirt wall red back box skirt wall white surface mount back box wall red surface mount back box wall white trim ring wall red trim ring wall white cd refers to strobes that include 135 150 177 and candela settings 5 21 2014 Page 3 of 4 and SpectrAlert are registered trademarks of and SpectrAlert is a trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited docu
