DN 7047 G cid 129 A0 126 Systems Series Control Annunciator NOTIFIER NCA 2 is a second generation Network Con Annunciator for the NOTI network com for use with ONYX Series nodes such as the NFS2 NFS 3030 NFS 320 NFS 640 and NFS2 640 fire control panels as well as first generation NCA Net Control Annunciators Additionally the NCA 2 may be with DVC Series products to create one or more Audio Command Centers on NOTI cid 129 FIRE cid 129 NET The provides system control and display capabilities for or for selected network nodes NCA 2 display consists of a 640 character backlit LCD and a control interface consisting of keys used navigate screen menus keys with fixed control func and a QWERTY keypad connected to one or more networked panels the provides network control and status history display It may also be configured as the Primary Display displayless nodes on the network Features Certified for seismic applications when used with the seismic mounting kit Approved for Marine applications when a marine listed is used with marine listed compatible equipment DN 60688 Full supervision of all inputs and network integrity Enhanced format 640 character LCD display with back ACS bus for LED or graphic annunciators EIA 485 Optically isolated printer interface EIA 232 11 LED status indicators Power Controls Active Fire Pre Alarm Security Alert Supervisory Trouble Silence CPU Failure Point Disabled Other Event Alphanumeric QWERTY rubber keypad Four status relays Alarm Trouble Supervisory Security Nonvolatile real time clock can be synchronized with net by master node Optional Security Keyswitch enables keypad functions Optional Security Tamper switch Supports up to 32 remote ACS annunciators and mod Requires 24 VDC and a network connection RDP port for LCD 160 or terminal mode LCD2 80 NCA 2 Firmware version 14.0 and higher can support on the RDP port or LCD2 80 in terminal mode but not at the same time Features Enable Disable or Group Enable Disable local networked ONYX series panels in ABS 2D backbox Control ON OFF networked ONYX series panel control Read Status networked ONYX series panel points and Network paging control HVAC control Network wide Acknowledge Silence Reset Lamp Test local to NCA 2 History Buffer 1000 Alarm events 4000 System events Print NCA 2 programming and history reports Report status of networked panels and their respective devices to a central station via a single UDACT 2 see sheet DN 60686 One Master level nine User level passwords The Master assign each User access levels programming alter Summary Event Count display event handling Online programming and alter status programs user guidance program including interactive soft Enhanced Read Status Alter Status displays New history filters for report displaying and printing All Only Alarms Only Troubles Only Supervisory Security Time Interval Point Range Fully programmable node mapping subsystem Advanced Basic Walk Test program Timer control for Auto Silence AC Fail Delay Meets Canadian ULC display requirements Environmental adjustment controls to maximize LCD legi Meets NFPA requirements for Firefighter Smoke Control FSCS and HVAC 3 1 17 Page 1 of 4 NCA 2 version 20 and higher complies with UL 2572 Mass Systems Indicators and Controls INDICATORS POWER green illuminates when 24 VDC power is applied goes out if power is removed and NCA 2 is using a CONTROLS ACTIVE green illuminates to indicate that the control functions are active SIGNAL SILENCE press this key to turn off all control mod notification appliance circuits and panel output cir that have been programmed as Silenceable SYSTEM RESET press this key to clear all latched alarms other events and turn off event LEDs DRILL HOLD 2 SEC press this key holding it down for two to activate all silenceable output circuits FUNCTION KEYS PRINT SCREEN press this key to print what is currently on LCD screen FIRE ALARM red illuminates when at least one fire alarm exists flashes when any of these events remain LAMP TEST press this key to test the LED indicators on left of the keypad and to check firmware revision num PRE ALARM red illuminates when at least one pre alarm exists flashes when any of these events remain SECURITY blue illuminates when at least one security exists flashes when any of these events remain SUPERVISORY yellow illuminates when at least one event exists i e sprinkler valve off normal pressure fire pump running guard tour etc when any of these events remain unacknowl SYSTEM TROUBLE yellow illuminates when at least one event exists flashes when any of these events unacknowledged OTHER EVENT yellow illuminates for any category of not listed above flashes when any of these events unacknowledged SIGNALS SILENCED yellow illuminates if the NCA 2 key has been pressed or if any other node sent a Silence command flashes if only some points on node are silenced POINT DISABLED yellow illuminates when at least one dis exists on the network or in the system CPU FAILURE yellow activated by the watchdog timer indicates an abnormal hardware or software Contact technical support FUNCTION KEYS Acknowledge Signal Silence System Reset Drill Alarm Signal Fire Alarm Scroll Display Security Scroll Display Supervisory Scroll Display Trouble Scroll Display Other Event Scroll Display five keys labeled SCROLL DISPLAY allow the user to scroll messages for the particular event type For example the FIRE ALARM SCROLL DISPLAY key will scroll all fire alarm events as details of each are shown in display area of the NCA 2 The OTHER EVENT SCROLL DISPLAY key also scrolls Pre Alarm and Disabled events ACKNOWLEDGE press this key to acknowledge off all events 2 of 4 DN 7047 G cid 129 3 1 17 NEXT SELECTION PREVIOUS SELECTION these keys are when setting parameters in NCA 2 data fields for choosing a device type as a filter for requesting Node History BATTERY LEVEL press this key to display voltage and current level for system batteries Displays levels local AMPS 24 E or AMPS 24 E connected to asso NFS2 3030 or NFS 3030 node and humidity ranges This system meets NFPA for operation at 0 to 49 32 to 120 at a relative humidity noncondensing of 85 at 30 per NFPA and 93 2 at 32 2 89.6 per ULC However the useful life of the system batteries and the electronic components may be affected by extreme temperature ranges and Therefore it is recommended that this system and peripherals be installed in an environment with a nominal temperature of 15 to 27 60 to 80 Product is 3 lbs 1.36 kilograms REQUIREMENTS NCA 2 may be powered from a Main Power Supply see data sheet DN 6883 mounted in a seper cabinet see specifications below or from any UL Listed 24 VDC source from a NOTIFIER fire panel panel data sheets The battery on the NCA 2 mother is for RTC and SRAM holds the history memory power failure Replacements are available P N Power source 1 AMPS 24 120 VAC 50 60 Hz 4.5 maximum or AMPS 24E 240 VAC 50 60 Hz 2.25 A max power supply 2 the NFS 640 NFS2 640 and
