Notifier NFS2-640(E) Data Sheet

File Preview
File Preview
Click below to download for free

File Data

Name notifier-nfs2-640-e-data-sheet-5820164379.pdf
Type PDF
Size 886.92 KB

Text Preview

NFS2 640 Intelligent Addressable Fire Alarm Control Panel NFS2 640 intelligent Fire Alarm Control Panel is part of the Series of Fire Alarm Controls from NOTIFIER stand alone or network configurations ONYX Series products virtually every application requirement NFS2 640 modular design makes system planning easier The can be configured with just a few devices for small building or networked with many devices to protect a large cam or a high rise office block Simply add additional peripheral to suit the application host of other options are available including single or multichan voice firefighter telephone LED LCD or PC based graphic networking advanced detection products for challeng environments wireless fire protection and many additional Unless called out with a version specific at the end of the part refers to models NFS2 640 and NFS2 640E simi refers to models CPU2 640 and CPU2 640E Certified for seismic applications when used with the appropriate mounting kit Approved for Marine applications when used with listed compati equipment See DN 60688 One expandable to two isolated intelligent Signaling Line Circuit Class A B or X Wireless fire protection using SWIFT Smart Wireless Integrated Technology See DN 60820 Up to 159 detectors and 159 modules per SLC 318 devices per per FACP or network node Detectors can be any mix of ion photo thermal or multi sen wireless detectors are available for use with the FWSG Modules include addressable pull stations normally open con devices two wire smoke detectors notification or relay modules are available for use with the FWSG Standard 80 character display 640 character display or display less a node on a network Network options High speed network for up to 200 nodes NFS2 3030 NFS2 NFS 320 C NFS 320SYS NCD NCA 2 DVC EM NFS 3030 NFS 640 and NCA Standard network for up to 103 nodes NFS2 3030 NFS2 640 NFS 320SYS NCD NCA 2 DVC EM NCS NFS 3030 NFS 640 NCA AFP 200 AFP AFP 1010 and AM2020 Up to 54 nodes when DVC is used in network paging 6.0 A switch mode power supply with four Class A B built in Noti Appliance Circuits NAC Selectable System Sensor or Gentex strobe synchronization Built in Alarm Trouble Security and Supervisory relays Field programmable on panel or on PC VeriFire Tools online or offline programming utility Upload save store check compare and simulate panel data Upgrade panel firmware Autoprogramming and Walk Test reports Multiple central station communication options Standard UDACT Internet Internet GSM 80 character remote annunciators up to 32 EIA 485 annunciators including custom graphics Printer interface 80 column and 40 column printers History file with 800 event capacity in nonvolatile memory plus 200 event alarm only file Alarm Verification selection per point with automatic counter Presignal Positive Alarm Sequence PAS Silence inhibit and Auto Silence timer options March time temporal California two stage coding strobe synchro Full QWERTY keypad Battery charger supports 18 200 AH batteries Non alarm points for lower priority functions Remote ACK Signal Silence System Reset Drill using monitor Automatic time control functions with holiday exceptions Surface Mount Technology SMT electronics Extensive built in transient protection Powerful Boolean logic equations Support for SCS Series smoke control system in HVAC mode AS PRIMARY DISPLAY Backlit 640 character display Supports SCS Series smoke control system in FSCS mode when is connected to the NCA 2 used as primary display Supports DVC digital audio loop Printer and CRT EIA 232 ports EIA 485 annunciator and terminal mode ports Alarm Trouble Supervisory and Security relays 12 20 2020 Page 1 of 9 WIRELESS Self healing mesh wireless protocol Each SWIFT Gateway supports up to 50 devices 1 wireless gate and up to 49 SWIFT devices Up to 4 wireless gateways can be installed with overlapping net coverage FEATURES Ten independent hazards Sophisticated cross zone three options Delay timer and Discharge timers adjustable Abort four options Low pressure CO2 listed VOICE AND TELEPHONE FEATURES Up to eight channels of digital audio 35 50 75 and 100 125 watt digital amplifiers DAA2 DAX series DS series NCA 2 required as primary display Solid state digital message generation Firefighter telephone option 30 to 120 watt high efficiency amplifiers AA Series Backup tone generator and amplifier option NFS2 640 can also integrate with the FirstCommand Emer Communications System See DN 60772 OFFLINE SWITCHING A POWER SUPPLY 6.0 A IN ALARM 120 VAC NFS2 640 240 VAC NFS2 640E Displays battery current voltage on panel with display INTELLIGENT FEATURES Polls up to 318 devices in less than two seconds Activates up to 159 outputs in less than five seconds Multicolor LEDs blink device address during Walk Test Fully digital high precision protocol U S Patent 5,539,389 Manual sensitivity adjustment up to nine levels Pre alarm ONYX intelligent sensing up to nine levels Day Night automatic sensitivity adjustment Sensitivity windows Photo 0.5 to 2.35 foot obscuration High Sensitivity Photoelectric VIEW Open Air Protection 2.0 ft obscuration Special Applications 0.02 obscuration Multi Criteria Detector Open Air Protection 2.52 3.89 ft Special Applications 1.13 2.52 ft obscuration Drift compensation U S Patent 5,764,142 Degraded mode In the unlikely event that the CPU2 640 micro fails FlashScan detectors revert to degraded operation can activate the CPU2 640 NAC circuits and alarm relay of the four built in panel circuits includes a Disable Enable for this feature Multi detector algorithm involves nearby detectors in alarm deci U S Patent 5,627,515 Automatic detector sensitivity testing NFPA 72 compliant Maintenance alert two levels Self optimizing pre alarm to 32 remote displays display no display cabinet size shown Page 2 of 9 DN 7111 N cid 129 12 20 2020 Intelligent Loop 1 Contact Intelligent Loop 2 annunciator control points Control Annunciator Graphics 636 point UDACT phone to Series Printer SERIES VIEW VERY INTELLIGENT EARLY WARNING SMOKE DETECTOR Advanced ONYX intelligent sensing algorithms differentiate smoke and non smoke signals models IV support CLIP mode as well as FlashScan Addressable operation pinpoints the fire location ULC listed models available models are ULC Listed is retrofit backwards compatible for use with older panels ADVANCED MULTI CRITERIA FIRE CO DETECTOR Detects all four major elements of a fire smoke heat CO and 135 57.2 fixed temperature heat detector Transmits an alarm signal due to heat Separate signal for life safety CO detection Optional addressable sounder base for Temp 3 fire or Temp 4 tone Automatic drift compensation of smoke sensor and CO cell High nuisance alarm immunity ULC listed models available A models are ULC Listed INTELLIGENT MULTI CRITERIA DETECTOR Combined Photoelectric Thermal and Infrared Sensor UL 268 7th Edition and UL 521 Listed Canadian
