Notifier NFW-50X Intelligent Addressable FACP with Communicator

NFW 50X Intelligent Addressable FACP with Communicator FireWarden 50X NFW 50X is the latest intelligent address fire alarm control panel FACP within the FireWarden Series is a direct replacement for the FireWarden 50 NFW 50 The comes with a pre installed communicator and supports up 50 addressable devices in any combination of detectors or mod With an extensive list of powerful features the NFW 50X pro just like FireWarden 100 products yet fits into applications served only by conventional panels pre installed IPOTS COM is a dual technology POTS and IP The POTS transmits system status alarms troubles loss etc to a Central Station via the public switched telephone The IP communicator internet monitoring capability sends signals over the Internet saving the monthly cost of two dedi business telephone lines Although not required the second telephone line may be retained providing backup communication the public switched telephone line Optional cellular reporting is using the CELL MOD or CELL CAB N and local programming of the control panel is possible using FS Tools Upload Download utility Programming databases can uploaded downloaded via the panel USB port and USB cable via an ethernet connection using the IPOTS COM communicator USB port also allows for the download or upload of the entire history file walk test data current status and system volt by means of a USB flash drive power supply and all electronics are contained on a circuit supported on a new quick install chassis and housed in a cabinet Available accessories include local and remote software remote annunciators and reverse polar box transmitter 4XTM Listed to UL Standard 864 10th edition Pre installed IPOTS COM Ethernet IP and POTS Plain Old Tele Service Central Station Communicator Optional CELL MOD or CELL CAB N GSM Central Station Com over AlarmNet Compatible with SWIFT wireless devices Auto programming learn mode reduces two devices set to the same address Two independently programmable built in Style Z Class A or Y Class B NAC circuits Selectable strobe synchronization for System Sensor Wheelock Gentex devices 80 character LCD display with backlighting Notification Appliance Circuit End of Line resistor matching Four programmable function keys for ease of maintenance Two programmable relays and one fixed trouble relay Built in Programmer Real time clock calendar with automatic daylight savings control History file with 1,000 event capacity Addressable sounder base Control module delay timer Automatic detector sensitivity testing NFPA 72 compliant Automatic device type code verification Point trouble identification Waterflow selection per module point Alarm verification selection per detector point Maintenance alert warns when smoke detector dust accumula is excessive One person audible or silent walktest with walktest log printout System alarm verification selection per detector point PAS Positive Alarm Sequence and Pre signal per point NFPA compliant Up to 16 ANN BUS annunciators 8 per each ANN Bus Remote Acknowledge Alarm Silence Reset and Drill via modules or remote annunciator Upload Download of program and data via USB with optional FS Programming Utility COMMUNICATION LOOP Supports FlashScan and CLIP protocols SLC operates up to 10,000 ft 3,000 m in FlashScan mode with Single addressable SLC loop which meets NFPA Class B and 50 addressable device capacity any combination of addressable unshielded wire A requirements and modules Compatible with NOTIFIER FireWarden ONYX Series address devices refer to the FireWarden SLC Wiring Manual APPLIANCE CIRCUITS NACS Two independently programmable output circuits Circuits can be for the following outputs Style Y Class B Style Z Class A Silence Inhibit and Autosilence timer options Continuous March Time Temporal or California code for main board NACs with two stage capability Selectable strobe synchronization per NAC 2.5 A special application 250mA regulated total power for NACs Maximum or total 24VDC system power shared between all NAC and the ANN BUS is 2.7 A AND SOFTWARE Autoprogramming learn mode reduces installation time Custom English labels per point may be manually entered or from an internal library file Two programmable Form C relay outputs 50 software zones Continuous fire protection during online programming 7 16 2018 Page 1 of 4 Program Check automatically catches common errors not linked any zone or input point OFFLINE PROGRAMMING Create the entire program in your using FS Tools a Windows software package and system programming locally Offline program requires an ethernet connection FS Tools is available on interface INDICATORS Fire Alarm red AC Power green Trouble yellow Battery fault yellow Maintenance yellow Alarm Silenced yellow CO Alarm red Supervisory yellow Ground fault yellow Disabled yellow Communication yellow F1 F4 Programmable Function yellow Acknowledge Drill Manual Evacuate 16 key alpha numeric pad Alarm Silence Four 4 programmable function keys Reset lamp test Line Information Addressable Fire Alarm Control Panel with one SLC Includes main circuit board with display pre installed IPOTS communicator chassis with transformer backbox with door bag containing screws cables key etc Programming software for Windows PC com Available for download at www notifier com Optional GSM communicators Dual technology POTS and IP communicator board Optional dress panel for the NFW 50XR red Optional dress panel for NFW 50X black Optional trim ring for semi flush mounting Black For order TR CE Optional cabinet for one or two modules Optional cabinet for up to six modules mounted on CHS 6 Battery backbox holds up to two 25 AH batteries CHG 75 Battery box houses two 55 AH batteries Chassis mounts up to six multi modules in a BB 25 cabinet Battery charger for lead acid batteries with a rating of 25 to AH Remote battery charging system for lead acid batteries a rating of 55 to 120 AH Requires additional NFS LBB for CHG 120 or CHG 75 required for batteries larger than 18AH Series Batteries see data sheet DN 6933 Series UL listed compatible event printer Uses tractor fed MODULES Reverse Polarity Transmitter Module Provides a super output for local energy municipal box transmitter alarm and Includes a disable switch and disable trouble LED ANNUNCIATORS Remote black LCD annunciator mimics the information on the FACP LCD display Recommended wire type is un Remote LCD annunciator mimics the information dis on the FACP LCD display Recommended wire type is un For use in FM applications only Basic model is black Page 2 of 4 DN 60955 C 7 16 2018 R for red LED Driver Module provides connections to a user sup graphic annunciator See DN 7105 Annunciator Module provides three LEDs for each Alarm Trouble and Supervisory Ships with red enclosure DN 60242 Provides alarm red indicators for up to 30 input or addressable points See DN 60242 Relay Module provides 10 programmable Form C Can be mounted inside the cabinet See DN 7107 Serial Parallel Printer Gateway module provides a for a serial or parallel printer See DN 7103 DEVICES Addressable low profile photoelectric smoke detector only Addressable low profile photoelectric smoke detector FlashScan and CLIP mode Addressable low profile photoelectric smoke detector base included Fla
