Notifier NH-200 Series Intelligent Addressable Thermal Detectors

NH 200 Series Addressable Heat Detectors for FireWarden Series NOTIFIER NH 200 Series intelligent thermal detectors are for both performance and aesthetics and are direct for the NH 100 Series A new modern sleek contem design and advanced thermal technologies make the NH 200 ideal for both system operation and building design The ID address set using rotary decimal switches provide specific locations with FireWarden Series fire alarm control panels the includes a 135 fixed temperature rate of rise and a fixed high temperature detectors These thermal detec provide effective intelligent property protection in a variety of Detectors are available for both FlashScan and CLIP as designated LOOP Two wire SLC loop connection Unit uses base for wiring Addressable by device Rotary decimal addressing to the FireWarden panel manuals for device capacity Designed to meet UL 268 7th Edition Sleek low profile stylish design State of the art thermistor technology for fast response Built in tamper resistant feature Built in functional test switch activated by external magnet Fixed temperature model NH 200 factory preset to 135 communications and built in device type identification Rate of rise model NH 200R 15 8.3 per minute High temperature model NH 200H factory preset to 190 360 viewing angle of the two visual alarm indicators LEDs red in Normal condition and turn on steady red in Alarm LEDs blink every time the unit is polled Sealed against back pressure SEMS screws for wiring of the separate base Designed for direct surface or electrical box mounting Plugs into separate base for ease of installation and maintenance Separate base allows interchange of photoelectric ionization and sensors SYSTEM FEATURES Remote test feature from the panel Walk test with address display Low standby current Remote LED output connection to optional RA100Z remote LED Flanged surface mounting kit Series plug in intelligent thermal detectors use a detachable to simplify installation service and maintenance Installation are shipped with each detector detector base all base types on an electrical backbox which at least 1.5 3.81 cm deep For a chart of compatible junction see DN 60054 Because of the inherent supervision provided by the SLC loop resistors are not required Wiring or branches are for Style 4 Class wiring only using relay or sounder bases consult the N100 ISO installation I56 3625 for device limitations between isolator modules and iso bases thermal detectors for protection of property For further informa refer to I56 6522 Applications Manual for System Smoke which provides detailed information on detector spacing zoning wiring and special applications detectors are constructed of fire resistant plastic The NH Series plug in intelligent thermal detectors are designed to com standards and offer an attractive appearance NH 200 Series detector uses one of the panel addresses limit is panel dependent on the FireWarden Signaling Line Cir SLC It responds to regular polls from the control panel and its type and the status If it receives a test command from the or a local magnet test it stimulates its electronics and an alarm It blinks its LEDs when polled and turns the LEDs when commanded by the panel The NH 200 Series offers fea and performance that represent the latest in thermal detector 6 26 2019 Page 1 of 3 Ivory Low Frequency Intelligent programmable base Produces a fundamental frequency of 520 Hz with a square wave or its equivalent designed to meet the 72 sleeping space requirement Intended for retrofit applica CSFM 7300 1653 0238 KITS AND ACCESSORIES White replacement flange for B210LP A base Ivory replacement flange for B210LP A base Remote LED annunciator 3 32 VDC Mounts to a U S sin electrical box For use with B501 A and B300 6 A Test magnet Test magnet with telescoping handle Color Kit includes cover and trim ring white 10 pack Color Kit includes cover and trim ring ivory 10 pack Color Kit includes cover and trim ring black 10 pack Line Information suffix indicates CLIP and FlashScandevice White low profile intelligent 135 fixed thermal sensor only Ivory low profile intelligent 135 fixed thermal sensor and CLIP White low profile intelligent rate of rise thermal sensor only Ivory low profile intelligent rate of rise fixed thermal FlashScan and CLIP White low profile intelligent 190 fixed thermal sensor only Ivory low profile intelligent 190 thermal sensor and CLIP BASES For details on intelligent bases see DN 60981 White 6 base standard flanged low profile mounting base 7300 1653 0109 Ivory 6 base standard flanged low profile mounting CSFM 7300 1653 0109 Bulk pack of B300 6 package contains 10 White 4 standard European flangeless mounting UL ULC listed CSFM 7300 1653 0109 Black 4 standard European flangeless mounting base listed CSFM 7300 1653 0109 Ivory color 4 standard European flangeless mounting UL ULC listed CSFM 7300 1653 0109 Bulk pack of B501 WHITE contains 10 White relay base CSFM 7300 1653 0216 Ivory relay base CSFM 7300 1653 0216 White isolator detector base CSFM 7300 1653 0216 Ivory isolator detector base CSFM 7300 1653 0216 White Intelligent addressable sounder base capable of sound output in high or low volume with ANSI Temporal 3 Temporal 4 continuous tone marching tone and custom tone FlashScan protocol CSFM 7300 1653 0213 Ivory Intelligent addressable sounder base capable of sound output in high or low volume with ANSI Temporal 3 Temporal 4 continuous tone marching tone and custom tone FlashScan protocol CSFM 7300 1653 0213 White Low Frequency Intelligent programmable base Produces a fundamental frequency of 520 Hz with a square wave or its equivalent designed to meet the 72 sleeping space requirement CSFM 7300 1653 0238 Ivory Low Frequency Intelligent programmable base Produces a fundamental frequency of 520 Hz with a square wave or its equivalent designed to meet the 72 sleeping space requirement CSFM 7300 1653 0238 White Intelligent sounder base capable of producing output with ANSI Temporal 3 or continuous tone Intended for applications CSFM 7300 1653 0213 Ivory Intelligent sounder base capable of producing output with ANSI Temporal 3 or continuous tone Intended for applications CSFM 7300 1653 0213 White Low Frequency Intelligent programmable base Produces a fundamental frequency of 520 Hz with a square wave or its equivalent designed to meet the 72 sleeping space requirement Intended for retrofit applica CSFM 7300 1653 0238 Page 2 of 3 DN 60980 B 6 26 2019 UL Applications 0.5 to 4.0 per foot obscuration is 0.5 to 3.5 2.0 5.3 cm high base determines diameter B300 6 6.1 15.6 cm diameter B501 4 10.2 cm diameter a complete list of detector bases see DN 60981 weight 3.4 oz 95 g temperature range NH 200 NH 200R Series to 100 to 38 NH 200H Series to 150 to 66 spacing UL approved for 50 ft 15.24 m center to cen FM approved for 25 x 25 ft 7.62 x 7.62 m spacing humidity 10 93 non condensing ratings fixed temperature set point 135 57 rate of detection 15 8.3 per minute
