Notifier ONYX Series NCS Network Control Station

ONYX Series NCS Control Station NOTIFIER Network Control Station NCS is a high per desktop computer with text and color graphics dis capability of all network events and points The NCS runs the user friendly Windows environment The NCS is ideal addition to NOTI see Ordering Infor for version compatibility when network monitoring and are required 2.0 GHz Pentium IV microprocessor Hardware Features computer consisting of 1 GB RAM 80 GB hard drive 104 key keyboard PS 2 mouse 300 Watt power supply CD RW DVD ROM drive Sound card and microphone 19 flat screen LCD monitor Software Features Windows XPProfessional operating system Pager interface Mouse control with extensive use of Windows style Vectors to a screen displaying an alarm with or without Cursor changes automatically to indicate on screen action click operation intervention New and Acknowledged Event boxes display all off normal simultaneously with graphic screens Operator log on with response tracking History Manager records operator event and response time and date stamp to hard drive Multiple search filters make History Manager a powerful tool An unlimited number of events can be stored in the history A warning is generated every 100 events after events are stored A complete library of device icons is included Custom device icons can be created in the field Add edit and delete devices and screens in the field A complete library of HAZMAT and information labels for areas that present an extra hazard to personnel Link devices or system events to voice wav text or bit All software backed up on CD RW DVD ROM Read Status Program Edit window network points files Walk test over the network NFS2 3030 NFS 3030 NFS and NFS 320 only Systems Software Version window obtain software version num for network panels NFS2 3030 NFS 3030 NFS 640 NCA NCS NWS and BACnet Gateway Secure Desktop is bundled with NCS and allows the to restrict access to the Windows XP Pro Microsoft Excel 2000 is bundled with the NCS to fully uti the spreadsheet option when running VeriFire Tools Up to five states can be visually represented for each input Normal Trouble Alarm Pre Alarm detectors Dis Up to four states can be visually represented for each out device Normal Trouble Active Disabled Up to two states can be visually represented for each Sys Trouble Normal Trouble Off Normal Event window color coded Network wide Disabled Device window Mini History viewer last 1,000 events color coded Upload Download NFS2 3030 NFS 3030 NFS2 640 NFS 320 NCA AM2020 and AFP1010 data over the network Download NFS2 3030 NFS 3030 NFS2 640 NFS 640 NCA 2 and NCM application code over the net Login Logout Change Password Hundreds of operators passwords Programmable access per feature per node per user Logs in history any programming changes GSP Graphic Setup Program imports DWG formatted files to BMP Graphic Editing and Navigation aids on site modifiable 05 19 2009 Page 1 of 2 SVGA 1024 x 768 color graphics Programmable Alarm and Trouble tones variable fre Control ON OFF all networked NFS2 3030 NFS 3030 NFS 640 NFS 320 NCA 2 AM2020 AFP 400 AFP 300 output points Enable Disable or Group Enable Disable all net NFS2 3030 NFS 3030 NFS 640 NFS 320 NCA AFP1010 AFP 400 AFP 300 points and zones Archived history files DIMENSIONS Desktop Rackmount Unit Width 482 19.0 Depth 450 mm 17.7 Height 177 mm 7.0 17.5 kg 39 lbs NOTE Dimensions subject to Contact NOTIFIER for further information ELECTRICAL AC Input frequency 50 60 Hz 7.0 A V 95 132 V 4.0 A 230 V 185 264 V DIMENSIONS 19 Flat screen LCD Color Moni Width 418 mm 16.5 Height 427.8 mm 16.8 Depth mm 7.9 Weight 6.5 kg 14.3 lbs NOTE Dimen subject to change Contact NOTIFIER for further infor ELECTRICAL AC Input 1.7 A 100 240 50 60 Hz auto adjust Power consumption 40 watts Listings and Approvals listings and approvals apply to the NCS In some cases modules or applications may not be listed by certain agencies or listing may be in process Consult fac for latest listing status UL ULC Listed S635 Version 5.0 network only UL Listed S624 Version 3.0 network only ULC Listed CS118 Version 3.0 network only FM approved NFS2 640 NFS 640 NFS2 3030 NFS NFS 320 NCA NCA 2 except NCS4 W F ONYX CSFM approved file 7300 0028 221 except NCS4 W F Information The PC and monitors are warranted from date purchase for a period of 12 months Please refer to NOTI Limited Warranty Policy for additional information NCS equipment options requirements are available versions 5.0 4.0 and 3.0 as follows VERSION 5.0 NETWORK NCS version 5.9 for wire network With 19 color flat screen LCD monitor graphics capability an NCS NCWPCA version 2.0 NCS version 5.9 for fiber network With 19 color flat screen LCD monitor graphics capability an NCS NCFPCA version 2.0 Network Control Annunciator version 14.1 Network Control Annunciator version minimum 3.0 Requires version 4.3 or higher firmware for DIA CPU version version 4.3 or higher LIB and 5.81 firm for SIB AROM5.0M SIB Requires version 4.3 or higher firmware for DIA CPU version version 4.3 or higher LIB and 5.81 firm for SIB AROM5.0M SIB Requires version 5.0 firmware for wire network Requires version 5.0 firmware for fiber network NFS 640 version 3.4.3 NFS2 640 version 12.1 NFS 3030 version 2.11.7 NFS2 3030 version 14.1 or higher Network Communications Module version 3.40 for network Network Communications Module version 3.40 for network VeriFire Tools CD version 5.5 VeriFire for AM2020 AFP1010 Version 4.20 GATEWAY BACnet Gateway version 3.95 NFS NFS 3030 NFS 640 NCS NCA 2 NCA and AM2020 NOTI Web Server version 2.0 The NOTI version 5.0 network will NOT sup the INA There are no changes to the AFP 200 or AFP 300 panel code for this version of the network VERSION 3.0 NETWORK version 2.2 version 2.2 Intelligent Network Annunciator requires version 3.0 firm Requires version 3.2 or higher firmware for DIA CPU version 3.0 or higher LIB and 3.0 firmware for SIB Requires version 3.2 or higher firmware for DIA CPU version 3.0 or higher LIB and 3.0 firmware for SIB Requires version 3.0 firmware for wire network Requires version 3.0 firmware for fiber network VeriFire for AM2020 AFP1010 Version 3.4 2 The NOTI version 3.0 network will NOT sup the ONYX Series of products NFS 640 NFS 3030 NFS2 NCA NWS or BACnet Gateway is a trademark and ONYX Notifier and VeriFire are trademarks of Honeywell International Inc Microsoft and are registered trademarks of Microsoft Corporation Pentium Intel are registered trademarks of Intel Corporation AutoCAD is a trademark of Autodesk Inc Secure Desktop is a trademark of Automation Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited
