P2RHK 120 120 VAC Selectable Output SpectrAlert Advance selectable output outdoor 120V is rich with features guaranteed to cut installation and maximize profits SpectrAlert Advance series of notification appliances is to simplify installations with features such as plug in instant feedback messages to ensure correct installa of individual devices and field selectable candela settings installing the P2RHK 120 first attach the 120V mount plate to the outdoor back box provided with each unit connect the notification appliance circuit wiring to the terminals on the mounting plate attach the horn strobe to the mounting plate by insert the product tabs in the mounting plate grooves The will rotate into position locking the product pins into mounting plate terminals The device will temporarily hold place with a catch until it is secured with a captured mount screw SpectrAlert Advance series outdoor notification appli are rated between minus 40 degrees Fahrenheit and degrees Fahrenheit in wet or dry applications Plug in design Field selectable candela settings 135 150 177 185 Tamper resistant construction Outdoor products rated from to 151 Regulated 120VAC Rotary switch for horn tone and three volume selections Outdoor products listed to UL 1638 strobe and UL 464 outdoor requirements Outdoor products rainproof per UL 50 NEMA 3R Weatherproof back box included Single screw attachment Horn strobe 120VAC adapter mounting plate and weather back box included horn strobe shall be a System Sensor SpectrAlert Model listed to UL 1971 and UL 464 and be approved for fire protective service horn strobe shall be wired as a primary signaling notifica appliance and comply with the Americans with Disabilities requirements for visible signaling appliances flashing at over the strobe entire operating voltage range The light shall consist of a xenon flash tube and associated system The horn shall have three audibility and an option to switch between a temporal three pat and a non temporal continuous pattern These options set by a multiple position switch On four wire products the shall be powered independently of the sounder The on horn strobe models shall operate on a coded or non power supply Devices PRODUCTS Advance outdoor horn strobe shall be listed for use by UL and shall operate between minus 40 and 151 degrees Fahrenheit The products shall be for use with a System Sensor outdoor weatherproof box with half inch and three fourths inch conduit entries SPECIFICATIONS Temperature to 151 to 66 Flash Rate 1 flash per second Voltage Regulated 120 VAC Voltage Range 96 VAC Terminal Wire Gauge 12 to 18 AWG Wall mount Horns Strobes 5.6 L x 4.7 x 2.5 D 142 L x 119 mm W x 63.5 mm D Weatherproof Backbox 5.7 5.1 2.0 145 mm L 130 mm W 51 mm D DERATING K series products used at low temperatures listed candela must be reduced in accordance with this table Candela Candela rating Output cd 08 06 2009 Page 1 of 2 Line Information 2 wire Horn Strobe High cd Red Outdoor P2RHK 2 wire horn strobe MP120K adapter mounting plate and weatherproof back box cd refers to strobes that include 135 150 177 and 185 settings Listings and Approvals listings and approvals apply to the modules specified in document In some cases certain modules or applications not be listed by certain approval agencies or listing may in process Consult factory for latest listing status UL Listed S4011 S5512 S3593 CSFM 7300 653 187 outdoor strobes 7125 1653 188 MEA 582 06 E is a registered trademark of and SPECTRAlert Advance a trademark of Honeywell International Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 2 of 2 DN 60527 A 08 06 2009
