Notifier XP6-MA(A) Six Zone Interface Module
File Preview
Click below to download for free
Click below to download for free
File Data
Name | notifier-xp6-ma-a-six-zone-interface-module-5743098162.pdf |
---|---|
Type | |
Size | 1.12 MB |
Downloads |
Text Preview
XP6 MA A Zone Interface Module XP6 MA six zone interface module provides an between the intelligent alarm system and a two wire detection zone A common SLC input is used for modules and the initiating device circuits share a common supervisory supply and ground Otherwise each operates independently from the others first module is addressed from 01 to 154 while the remain modules are automatically assigned to the next five higher Provisions are included for disabling a maximum of unused modules All two wire detectors being monitored be two wire compatibility listed with the modules The transmits the status of a zone of two wire detectors to fire alarm control panel Status conditions are reported as open or alarm The interface module supervises the of detectors and the connection of the external power XP6 MA module has panel controlled bicolor LED indi The panel can cause the LEDs to blink latch on or off Six addressable Class B or three addressable Class A initi Removable 12 AWG 3.1 mm to 18 AWG 0.78 mm plug device circuits terminal blocks Status indicators for each point Up to two unused addresses may be disabled Rotary address switches Class A or Class B operation FlashScan or CLIP operation Mount one or two modules in a BB XP cabinet optional Mount up to six modules on a CHS 6 chassis in a CAB 3 CAB 4 Series BB 25 cabinet optional or EQ Cab Series Mounting hardware included current 2.0 mA SLC current draw with all used if some addresses are disabled the standby decreases current 40 mA assumes all six LEDs solid ON range 32 to 120 0 to 49 10 to 85 noncondensing 6.8 172.72 mm high x 5.8 147.32 mm wide 1.25 31.75 mm deep weight 1.1 lb 0.499 kg including packaging options CHS 6 chassis BB XP cabinet BB 25 CAB 3 Series cabinet see DN 3549 CAB 4 Series see DN 6857 or EQ series cabinet see DN 60262 gauge 12 AWG 3.1 mm to 18 AWG 0.78 mm is shipped in Class B position Remove shunt for A operation H 354 Devices SLC wiring resistance 40 or 50 ohms panel IDC wiring resistance 25 ohms supply voltage DC voltage 18 28 volts power Ripple voltage 0.1 Vrms maximum External supply 90 mA maximum per address in alarm In Class B 540 mA maximum for all six addresses in alarm In A operation 270 mA maximum for all three addresses in detectors See the Notifier Device Compatibility Listings and Approvals listings and approvals apply to the modules specified in document In some cases certain modules or applications not be listed by certain approval agencies or listing may in process Consult factory for latest listing status UL Listed S635 XP6 MA ULC Listed S635 XP6 MAA MEA Listed 386 02 E CSFM 7300 0028 0219 7165 0028 0243 FM Approved FDNY COA 6085 6121 City of Chicago City of Denver Line Information Six zone conventional detector interface module Same as above with ULC Listing 05 16 2013 Page 1 of 2 Optional cabinet for one or two modules Dimensions 9.234 23.454 cm wide 9.484 24.089 cm including x 12.218 31.0337 cm high x 0.672 1.7068 cm BACKBOX 9.0 22.860 cm wide 9.25 23.495 cm hinges x 12.0 30.480 cm high x 2.75 6.985 cm installed 7.150 18.161 cm wide overall x 7.312 cm high interior overall x 2.156 5.4762 cm deep Optional cabinet for up to six modules mounted on chassis below Dimensions DOOR 24.0 60.96 cm x 12.632 32.0852 cm high x 1.25 3.175 cm deep at bottom BACKBOX 24.0 60.96 cm wide x 12.550 cm high x 5.218 13.2537 cm deep Chassis mounts up to six modules in a CAB 3 Series DN 3549 CAB 4 Series see DN 6857 cabinet EQ Cab Series see DN 60229 or BB 25 and FlashScan are registered trademarks of Honeywell Inc by Honeywell International Inc All rights reserved Unauthorized use this document is strictly prohibited document is not intended to be used for installation purposes We try to keep our product information up to date and accurate cannot cover all specific applications or anticipate all requirements specifications are subject to change without notice more information contact Notifier Phone 203 484 7161 FAX 203 484 7118 in the U S A 2 of 2 DN 6925 D 05 16 2013
