System Sensor PDRP-1001-PDRP-1001A-PDRP-1001E Deluge-Preaction Control Panel Supplem

Supplement to PDRP 1001 PDRP 1001A PDRP 1001E Preaction Control Panel Manual the following pages of Number 50734 I56 993 01 D770 19 00 Revision B the corresponding revised pages 9 19 33 and 40 bars on these pages indicate new revised information for Revision B 50734SUP Rev B ECN 99 166 Specifications Power PDRP 1001 PDRP 1001A 120 VAC 50 60 Hz 1.2 amps PDRP 1001E 220 240 VAC 50 Hz 0.6 amps size minimum 14 AWG with 600V insulation Circuit lead acid only Charging Circuit 27.6V 1.5 amps Battery Capacity 15 AH Batteries larger than 12 AH require Notifier or other UL listed battery cabinet Device Circuits circuitry Style B Class B Style D Class A Operating Voltage 24 VDC ripple 1.0V peak to peak current 15 mA minimum circuit current 40 mA maximum detector current in standby 2 mA max per zone loop resistance 200 ohms resistor 4.7K 1 2 Watt NOTIFIER part 71252 UL listed loop current is sufficient to ensure operation of one alarmed detector per zone current 5 mA including end of line resistor Appliance and Releasing Circuits circuitry allowable voltage drop due to wiring 2 VDC Operating Voltage 24 VDC current available to all external devices 2.25 amps signaling current per circuit 1.5 amps resistor 4.7K 1 2 Watt NOTIFIER part 71252 UL listed Circuit PTCs and Trouble Relays Form C contacts rated 2.0 amps 30 VDC resistive 0.5 amps 30 VAC resistive relays must be connected to a power limited power supply Smoke Detector Power to 200 mA is available for powering 4 wire smoke detectors ripple voltage 1.0 V p p Power DC current available from this output is up to 200 mA subtracted from four wire smoke power ripple voltage 1.0 V p p Regulated Power DC current available for powering external devices is 0.5 amp subtracted from 2.25 available to notification appliance circuits ripple voltage 100 mV p p For device compatibility data refer to the Device Compatibility Chart Appendix B PDRP 1001 PDRP 1001A Document 50734SUP Rev B 07 08 99 14.625 14.5 5.375 4.750 16.125 16 Trim Ring 1.6 1 Cabinet Dimensions PDRP 1001 PDRP 1001A Document 50734 Rev B 12 21 97 Power power required for the PDRP 1001 PDRP 1001A panel is 120 VAC 50 60 Hz 1.2 amps and power required for the PDRP 1001E is 220 240 VAC 50Hz 0.6 amps Overcurrent protection this circuit must comply with Article 760 of the National Electrical Code NEC and or local codes 14 AWG or larger wire with 600 volt rating Power polarity when connecting battery Connect battery cable to J9 on the main board using the plug connector provided See Appendix A for calculation of correct battery rating Batteries contain sulfuric acid which can cause severe burns to the skin and and can destroy fabrics If contact is made with sulfuric acid immediately flush skin eyes with water for 15 minutes and seek immediate medical attention monitor battery voltage and battery charging current a 4XMM NOTIFIER is required To install the meter module remove the jumper labeled AMP and connect cable assembly P2 to pin connector and cable assembly P3 to pin connector J3 on the main board Secure the 4XMM to the backbox with two screws provided On some models it will be necessary to install the meter bracket with the nuts bolts provided 3.5 2 Diagram of the 4XMM Voltmeter Connected to the Main Board PDRP 1001 PDRP 1001A Document 50734SUP Rev B 07 08 99 Optional Modules fire control panel has two module connectors J5 and J8 Three modules are available for the panel they can be used in any combination including duplicate modules The corresponding option jumper be cut before installation of an optional module to enable module supervision Jumper to install on J5 Jumper to install on J8 3.6 1 Optional Panel Modules Optional 4XLM module for an RZA 4X Annunciator must be installed on J7 and J8 only 4XTM and 4XZM modules can be installed in either location PDRP 1001 PDRP 1001A Document 50734 Rev B 12 21 97 C NFPA Standard Specific Requirements PDRP 1001 PDRP 1001A has been designed for use in commercial industrial and institutional and meets the requirements for service under the National Fire Protection Association NFPA outlined in this appendix The minimum system components required for compliance with the NFPA standards are listed below Control Panel containing the main control board cabinet backbox and door supply transformer and power supply refer to Appendix A for Standby Power Requirements Devices connected to one of the control panel Initiating Device Circuits Appliances connected to one of the control panel Notification Appliance Circuits Devices connected to one of the control panel Releasing Circuits following additional equipment is needed for compliance with the NFPA standards listed below 72 Signaling Systems for Central Station Service Protected Premises Unit 911AC DACT for connection to a compatible listed Central Station DACR or Protected Receiving Unit This unit must be installed as outlined in Figure C 1A 72 Auxiliary Fire Alarm System Transmitter Module for connection to a compatible listed Local Energy Municipal Box This unit must installed as outlined in Figure C 2 72 Remote Station Fire Alarm System Transmitter Module for connection to the Fire RS82 9 Remote Station Receiver See Figure for installation instructions for this unit OR 911AC DACT or Fire MS 5012 For connection to a compatible listed remote station This unit must be installed as outlined in Figures C 1A and C 1B Applications which require the NOTI FIRE 911AC are not FM approved PDRP 1001 PDRP 1001A Document 50734SUP Rev B 07 08 99 C 1A NFPA 72 Signaling Systems for Central Station Service Unit and Remote Station Protective Service 911AC DACT for connection to a Central Station Receiver or Protected Premises Receiving This unit must be installed as illustrated below For additional information on the 911AC refer to 74 06200 005 connections between the FACP and 911AC must be in conduit less than 20 in length in the same room This application using the NOTI FIRE 911AC is not FM approved Central DACT on STD DACT jumper over pins 2 3 DACT when a DACT This the control panel to all trouble conditions AC LOSS PDRP 1001 PDRP 1001A Document 50734 Rev B 12 21 97 PDRP 1001 PDRP 1001A Document 50734 Rev B 12 21 97 Warranty SENSOR warrants its products to be free from defects in materials and for eighteen 18 months from the date of manufacture under normal and service Products are date stamped at time of manufacture The sole and obligation of SYSTEM SENSOR is to repair or replace at its option free of for parts and labor any part which is defective in materials or workmanship normal use and service For products not under SYSTEM SENSOR manufacturing control the warranty is eighteen 18 months from date of original purchase SYSTEM SENSOR distributor unless the installation instructions or catalog sets a shorter period in which case the shorter period shall apply This warranty is if the product is altered repaired or serviced by anyone other than SYSTEM SENSOR its authorized distributors or if there is a failure to maintain the products and systems which they operate in a proper and workable manner In case of defect phone SENSOR Repair Dep
