Vesda VLS Detector

File Preview
File Preview
Click below to download for free

File Data

Name vesda-vls-detector-5026473819.pdf
Type PDF
Size 1.39 MB

Text Preview

VESDA VLS VESDA VLS is similar to the VESDA VLP detector but includes a valve mechanism the inlet manifold and software control the airflow from the four pipes This configuration a single VESDA zone be divided into four separate for example distinguishing separate voids within a It Works VLS draws air from all sectors use If the smoke level reaches Adaptive Scan Threshold the quickly scans each pipe to identify which pipe is carrying smoke If more than pipe is transporting smoke the sector with the highest smoke concentration is as the First Alarm Sector FAS Fast Scan is completed and the FAS identified the VLS continues to closely all four sectors pipes to monitor fire growth and maintain full protection of the are four alarm levels Alert Action Fire 1 and Fire 2 for each sector pipe and sensitivity for each alarm level can be set to ensure the optimum alarm thresholds applied for each sector VLS Display VLS display has a bar graph to indicate the overall smoke level alarm threshold fault indication The bar graph displays the individual sector smoke levels during scanning sequence There is an extra LED to indicate that a First Alarm Sector has been identified and an extra function to the Silence Button to allow for Scan to be initiated VLS display module can be mounted into the VLS front cover or remotely into a subrack or a remote box Options VLS detector can be fitted with a programmable 7 or 12 relay Termination card may be mounted in a remote box or in a 19in subrack status of the detector and all alarm service and fault events are transmitted to and external systems via VESDAnet VESDA fault tolerant communications The VESDAnet loop provides a robust bi directional communication network devices even allowing continued operation during single point wiring failures also provides system programming from a single location and forms the basis of the nature of the VESDA system and Referencing VLS has both the AutoLearn and Referencing software functions ensure optimum operation in different environments and to eliminate the occurrence nuisance alarms monitors the ambient environment and sets the most appropriate alarm Alert Action Fire 1 Fire 2 during the commissioning process ensures external pollution to a protected environment does not interfere the true smoke level being detected pipe identification Adaptive Scan Threshold Wide sensitivity range Laser based smoke detection VESDAnet communication 4 alarm levels per sector High efficiency aspirator Clean air barrier optics protection Easy to replace air filter 7 or 12 programmable relays option AutoLearn Referencing Event log Recessed mounting UL ULC FM LPCB VdS CFE ActivFire AFNOR VNIIPO CE EMC and CPD EN 54 20 Class A 40 holes 0.08 obs m Class B 40 holes 0.23 obs m Class C 60 holes 0.65 obs m of any configuration is using ASPIRE2 approvals listings and regulatory compliance vary between VESDA models Refer to www xtralis com for the latest product approvals VLS Mounting Box Termination Card Relay Version Termination Card Relay Version Information Programmer Mounting Kit Optional VSP 011 Programmer in Sub Rack Configuration Xtralis Configuration 7 Relay Version 12 Relay Version 7 Relay w FOK LED 12 Relay w FOK LED XX Blank Blate Programmer Scanner Display Detector Orientation Detector Orientation Product consult factory Americas 1 781 740 2223 Asia 852 2916 8876 Australia and New Zealand 61 3 9936 7000 and Europe 44 1442 242 330 Middle East 962 6 588 5622 contents of this document are provided on an is basis No representation or warranty either express or implied is made as to the accuracy or reliability of the contents of this document The manufacturer reserves the right to change designs or specifications obligation and without further notice Except as otherwise provided all warranties express or implied including without limitation any warranties of merchantability and fitness for a particular purpose are expressly excluded document includes registered and unregistered trademarks All trademarks displayed are the trademarks of their respective owners use of this document does not constitute or create a licence or any other right to use the name and or trademark and or label document is subject to copyright owned by Xtralis AG You agree not to copy communicate to the public adapt distribute transfer modify or publish any contents of this document without the express prior written consent of Xtralis no 09361 18 17873 Voltage 18 VDC Consumption 24 VDC Display or Programmer 3000 rpm 4200 rpm With Alarm Quiescent With Alarm W mA W mA W mA W mA WHD mm x 225 mm x 125 mm 13.8 in x 8.9 in x 4.9 in kg 9 lbs including Display and Programmer modules Conditions to 10 to 55 14 to 131 Ambient 0 to 39 32 to 103 Recommended Air 20 to 60 4 to 140 10 to 95 RH non condensing consult your Xtralis office for operation outside these or where sampled air is continually above 0.05 0.015 obs ft under normal operating conditions Conditions non operational life Up to 2 years Dry 95 0 to 85 C 32 to 185 not exposed to sunlight or other radiation sources Network length per pipe 100m 328 ft pipe length 200 m 650 ft flow per pipe 15 liters min Modelling Design Tool ASPIRE2 pipe lengths represent best practice for systems with pipe runs on each port no branching For longer and more complex pipe arrangements predictions of EN 54 20 are determined using ASPIRE2 Coverage to 2000 m2 21500 sq ft depending on local codes and Size Diameter 25 mm 1 in Diameter 15 mm 9 16 in in Relays or 12 Relays option rated 2 A 30 VDC 7 Relays NO NC contacts Alert Action Fire 1 Fire 2 Urgent Fault Isolate 12 Relays 10 x NO 2 x NO NC contacts Alert Action 1 Fire 2 Maintenance Urgent Fault Isolate First Alarm 1 to 4 and Scan Rating IP30 Access 8 x 25 mm 1 in knockouts in various positions Termination terminals 0.2 sq mm 30 AWG Range obs m 0.0015 obs ft Threshold Setting Range 0.005 obs m 0.0015 obs ft 0.010 obs m 0.0031 obs ft 1 0.015 obs m 0.0046 obs ft 2 0.020 obs m 0.0062 obs ft to 12 obs m 4 obs ft in UL mode Features Log Up to 18,000 events stored on FIFO basis Minimum 15 minutes maximum 15 days minimum period 1 day During AutoLearn are NOT changed from pre set values Compensation for external ambient conditions Alarm Levels per sector pipe Alert Action Fire 1 Fire 2 Fault Warning Levels Maintenance and Major fault Programmable Relays 7 or 12 Aids Filter Flow monitoring reporting via VESDAnet or Event Log Scan Threshold Detector selects the appropriate scan automatically Product UL listed for use from 0 to 38 32 to 104
