Potter AB-4 4 Inch Addressable Detector Base

File Preview
File Preview
Click below to download for free

File Data

Name potter-ab-4-4-inch-addressable-detector-base-3147896250.pdf
Type PDF
Size 996.64 KB

Text Preview

AB 4 SenSor BASe Sheet Intuitive Terminal Marking to assist with Installation Will mount to Single Double Gang Octagon or 4 Square Terminals will accept 14 to 22 AWG wire 7165 0328 0194 includes a 5 year warranty 4 base is used to mount the smoke or heat sensor to the electrical back box The AB 4 terminals are intuitively marked for installation and quick connection The base will accept 14 to 22 AWG wire The AB 4 will mount on a single gang double octagon or 4 square box Wiring Diagrams 1 Analog Detector Wiring Example FACP or the previous device on the SLC loop the next addressable device specifications are subject to change without notice For further information contact Potter Electric Signal Company Support Electric Signal Company LLC St Louis MO Cust Service 866 956 1211 Tech Support 866 240 1870 Canada 888 882 1833 www pottersignal com IN USA 8830014 REV A 1 1 OF 1
