CO 12 24 MONOXIDE CO DETECTOR UL listed to Standard 2075 12 or 24 VDC power input Low current draw 85dB at 10 sounder Form C alarm and trouble relay Self testing device 6 year warranty Wall or ceiling mount Operating temperature range 40 100 4.4 37.8 15 95 RH 14 22 AWG terminal size Contact rating 0.1A 30VDC non latching Specifications Carbon Monoxide detector shall be a system detector and shall be Potter CO 12 24 The detector shall have an operating range of 10 28 The normal stand by current draw shall not exceed 100 micro The wiring terminals shall accept wire from 22 to 14 AWG The shall have a form C Alarm and Trouble relay rated at 1 amps 30 VDC for monitoring detector shall be listed for wall or ceiling mount The detector shall a LED that flashes to indicate a normal condition The CO detector be UL listed to standard 2075 The detector shall have a button to a local silence of the sounder The sounder shall resound within minutes if an unsafe level of CO is still detected The sensor shall be for tampering as well as internal faults Detectors that do not the sensor shall not be acceptable is powered Signals Red LED flashes every 30 seconds indicating that the alarm Flashing red LED and pulsating horn Red LED flashes twice and horn beeps once every One chirp then red LED flashes 4 5 times followed by 2 alarm signals 30 seconds Monoxide CO is a toxic odorless tasteless colorless gas that is whenever organic compounds are involved in combustion Many utilize either propane natural gas or wood for heat and cooking and the burning of these fuels produce CO A malfunctioning or flue will fill a space with this toxic gas completely unknown the occupants Potter CO 12 24 utilizes the premium Carbon Monoxide CO technology for accurate detection and false alarm immunity CO 12 24 will only respond to the presence of CO and will not react other ordinary household chemicals that affect other detectors When CO is detected an 85 decibel sounder and the alarm relay activate indicate the presence of CO The sounder can be silenced for four 4 by pushing the Reset button CO 12 24 operates on 0 28 VDC supplied by an intrusion or fire The device emits a Temporal 4 pattern when the presence of is detected In addition to monitoring for tampering the detector monitors the sensor and detects if an internal problem exists If a occurs within the detector the trouble service a horn activates and trouble relay This monitoring feature also complies with the sensor requirement The CO 12 24 has a 6 year warranty and life After 6 years the detector needs to be replaced Response Times Levels parts per million parts per million parts per million parts per million Time response for 30 days 60 to 240 minutes 10 to 50 minutes 4 to 15 minutes Electric Signal Co LLC St Louis MO Cust Service 866 240 1870 Tech Support 866 956 1211 Canada 888 882 1833 www pottersignal com IN USA 8910250 REV C 1 OF 1
