CSS SERIES STROBE COMBINATION Field selectable wattage from 1 and 2 Watts Available 24VRMS and 70VRMS models Frequency range 400 to 4000 Hz Speaker UL listed for Fire Protective Service Strobe UL listed for ceiling and wall mount Strobe Speaker NFPA ANSI compliant Available colored light amber blue green and red Operable with 24V regulated DC or FWR 16 33V Polarized strobes with wide operating voltage range using filtered DC or unfiltered FWR input voltage Minimum one flash per second 1Hz Selectable light output candela low mid and high Synchronization requires SMD10 3A sync module terminal capacity up to 12 AWG back box skirt for surface mount optional retrofit plate allows mounting to a variety of boxes optional in red or white housing models mount to a 4 back box Specifications speaker and colored visual alarm indicating appliance shall be Model CSS25C CSS70C or equivalent device The speaker be NFPA ANSI compliant and listed under UL1480 standard for fire service The strobe shall be listed under UL 1638 standard for devices and shall be approved for fire protective and emergency In addition to lens color the reflective mirror shall also be of same color The amber blue green and red lens shall be listed in with UL 1638 Visual Appliance Private Mode Emergency General Utility or Emergency for use in indoor applications The output shall be field selectable having three settings of high or low light intensity output The speaker shall operate with amplifiers having an output of either 25V RMS or 70V RMS emergency evacutaion system and fire protection signaling systems speaker shall have a field selectable wattage from 1 or 2 Watts a frequency range of 400 to 4000 Hz The 24V DC signaling strobe be designed to produce a signal flash of one flash per second with applied minimum voltage The strobe speaker shall be of ceiling and wall mounting to a variety of back boxes using the SMD10 3A daisy chain or other source of Potter sync protocol low profile ceiling mount Colored Light Select A Strobe Speaker and CSS70C Series are designed to operate with distribution having an output either 25V RMS aor 70V RMS for emergency system and fire protection signaling systems The speaker is listed under UL1480 Speaker for Fire Alarm Emergency and and Professional Use and the colored light lens strobe series listed in compliance with UL1638 Visual Signaling Both meet or NFPA ANSI standards speaker series provide a 25V RMS input and CSS70C provide RMS with a colored light strobe The speakers incorporate a high speaker to reproduce a clear audible sound for maximum at minimum power across a frequency range of 400 Hz to 4000 Hz a capacitive input to allow for DC supervision The series provides a field selectable four wattage taps of 1 and 2 Watts The IN screw terminals accept 12 to 18 AWG wires colored light strobe can be selected either low medium or high a selectable slide switch located on the housing The colored light is in amber blue green or red The light output candela ratings depending on the lens color The series can be mounted on standard 4 electrical boxes and is available in red or white housing color In those where two or more Amseco horns and or strobes are connected require a synchronized code 3 temporal pattern and or a synchronized flash all models can be synchronized when used in conjuction with UL listed Sync Module SMD10 3A to meet the latest code Information Color Voltage Rating RMS Rate Output Mounting Type 24V Mid or or Wall Potter Customer Service for stock availability before ordering Electric Signal Co LLC St Louis MO Cust Service 866 240 1870 Tech Support 866 956 1211 Canada 888 882 1833 www pottersignal com IN USA 8850071 REV C 1 OF 2 Power Watts k Ohms Pressure dB 10ft Response Frequency Cut Off Specifications RMS 4000 Hz Hz RMS RMS Operating Current mA 24V DC 24V FWR 85 124 160 130 185 230 inches mm SERIES STROBE COMBINATION Required Minimum Output Mount 45 WITCH ig h cap id o w Square Box Skirt 174 View 35 70 View 25.5 85.7 IIRR View Diagram Evac S S L Next Device End of Line MODULE Next Device End of Line Square Box IN USA MKT 8850071 REV C 2 OF 2
