Features Provides 50 user configurable LED outputs provides 6 system LeD outputs power earth Fault Silenced Supervisory and Trouble Provides Audible PZT and 4 supervised dry contact inputs LeD outputs internally current limited no external resistor Maximum 31 DRV 50s for aFC 1000 p400 R pFC 6800 Maximum 10 DRV 50s for aFC 100 50 aRC 100 p300 200 100 pFC PFC 4064 Maximum p Link wire length is 6,500 feet product includes a 5 year warranty UUKL Listed for Smoke Control DRV 50 is a LeD driver module The DRV 50 using a RS 485 p Link connection to the providing 50 user configurable LED outputs and 4 dry contact inputs DRV 50 is connected to the fire alarm control panels using four wire RS 485 p Link connection This connection is limited and supervised The 50 programmable LED are located on connectors p1 p5 each containing LeD outputs and 2 5VDC outputs The system LeDs pZT control outputs are located on connector p6 The 4 dry contact inputs are located on connector P7 input circuits are power limited and use a UL Listed 5.1k resistor potter part 3005013 all outputs are power DRV 50 can be installed in the AE 2 AE 8 and AE 14 Enclosures The DRV 50 can also be installed the pSN 1000e Intelligent power Supply and larger panel enclosures that include space for mounting bracket modules UOXX S2930 Specifications Current VDC pWR Current VDC 33 VDC Panels ma alarm mA Standby mA maximum Standby ma maximum alarm Series Series Addressable Series product LED PWR can be provided by any fire listed source Output power be 16 VDC VDC and must be power limited Information Driver Module No page 1 OF 1 LED Driver ModulePotter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal com8830128 REv D 12 18firealarmresources com
