Features Provides an additional 12 Class B or 6 Class A Phone Circuits Equipped with stacker bracket for secure and accessible enclosures FFT EXP may be mounted in the FFT 1000 AE 8 or AE 14 FFT EXP is an expander module that provides 12 Class B or 6 A phone circuits The expander module connects to the FFT through the F Link and Voice terminals and is expandable up to 6 devices for Class B systems and up to fourteen 14 for Class systems maximum of two 2 FFT EXP can be mounted in the FFT 1000 FFT EXP may be mounted in the AE 8 and AE 14 remote All FFT EXP must be installed in the same room within 20 of the FFT 1000 and wiring must run in conduit mA mA Specifications Current 32 ft FFT Class B FFT Class A 30 86 noncondensing humidity PAGE 1 OF 4 Telephone Expander Module8830177 REV A 9 21Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comfirealarmresources com FFT EXP connects to the FFT 1000 using the F Link and Voice to establish communication The connections are power and supervised Each board is equipped with stacker bracket for and accessible mounting The FFT EXP must be installed within feet of the FFT 1000 and the wiring must run through conduit PAGE 2 OF 4 REV A 9 21Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comFFT EXPFirefighter Telephone Expander Modulefirealarmresources com Installation PAGE 3 OF 4 REV A 9 21Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comFFT EXPFirefighter Telephone Expander Modulefirealarmresources com AE 8 and AE 14 Installation P N 3992675 maximum four 4 FFT EXP P N 3992676 maximum six 6 FFT EXP can be stored in the AE 8 enclosure can be stored in the AE 14 enclosure Information FIRE FIGHTER SYSTEM 12 EXPANDER No PAGE 4 OF 4 REV A 9 21Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comFFT EXPFirefighter Telephone Expander Modulefirealarmresources com
