Potter INS-2500 Nitrogen Generator

Features potter Intelligen Controller Patent Pending Fully automates the air fill and nitrogen fill procedure Advance leak rate detection Integrated Bypass alarm Web Enabled system can be monitored anywhere there is connectivity Automatically emails trouble alerts and maintenance 7.5 HP lubricated tank mounted air compressor included to meet 13 required 30 minutes fill for 2,400 gallon system at 40 Handles up to 24,000 gallons of total sprinkler system capacity on NFPA 13 allowable leak rate of 1.5 PSI per 24 hours a new sprinkler system Three individual skids 80 gallon tank mounted air compressor cabinet and 120 gallon nitrogen tank Intelligen Series of Nitrogen Generators are specifically to generate on site 98 purity nitrogen for use in fire sprinkler systems When used as a supervisory gas in fire systems nitrogen slows corrosion improves the life of your and lowers maintenance costs INS 2500 utilizes nitrogen membrane technology for gas Nitrogen membranes are highly effective and a cost way of producing on site nitrogen Acting as a gas filter the membrane separates the oxygen and water vapor molecules the air from the nitrogen molecules The high purity nitrogen gas then piped through the air maintenance device and into the fire system As the system fills with nitrogen the remaining molecules in the fire protection system are exhausted by using Potter IntelliPurge Nitrogen Purge Valve The Potter IntelliPurge Purge Valve monitors the fire protection system to ensure purity nitrogen is consistent throughout the sprinkler system INS 2500 is to be connected to a new or existing fire sprinkler This system includes an air compressor nitrogen membrane air filtration equipment tanks and the Potter IntelliGen Controller Potter IntelliGen Controller ensures the contractor the easiest and operation of any nitrogen generator system in the industry unit is designed to be turned on and walk away The built in capabilities will make corrections and alert you to any changes lbs 1 4 x 21 H x 37 W x 24 D H x 31 W x 13 D Specifications Size Cabinet Tank Size Weight Cabinet Tank Compressor Supply in Operating Range 10 to 110 43 PSI lbs lbs 26.8A 230 240V 22.3A 460 480V 11.1A three Requires two 2 120 V connections for nitrogen cabinet and air blow down solenoid page 1 OF 4 Nitrogen Generator8820043 REV A 04 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comfirealarmresources com Potter INS 2500 should be installed in a dry clean and well ventilated room with ambient temperatures above 50 at all times Allow access to front for service and place the unit in a location that is conveniently located near fire sprinkler system connections a drain and a dedicated electrical The Potter IntelliGen Nitrogen Generator should always be installed in an adequately ventilated room Rapid release of nitrogen gas into enclosed space displaces the oxygen and can cause an asphyxiation hazard For detailed installation and operation instructions please refer to the Intelligen Nitrogen Generator Manual 5403646 Dimensions 1 CONNECTION PAGE 2 OF 4 REV A 04 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comINS 2500IntelliGen Nitrogen Generatorfirealarmresources com Dimensions 2 APART A APART ON A page 3 OF 4 REV A 04 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comINS 2500IntelliGen Nitrogen Generatorfirealarmresources com Dimensions 3 CONNECTION APART ON A Information Number 200 208VAC 3PH 60 HZ 230 240VAC 3PH 60 HZ 460 480VAC 3PH 60 HZ Nitrogen System 2500 200 208VAC Three Phase Nitrogen System 2500 230 240VAC Three Phase Nitrogen System 2500 460 480VAC Three Phase Nitrogen Purge Valve Purge Valve Air Maintenance Device Nitrogen Analyzer page 4 OF 4 REV A 04 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comINS 2500IntelliGen Nitrogen Generatorfirealarmresources com
