Potter NGP-2200D-M2 Nitrogen Generator with 2,200 Gallon Largest Riser Fill and 3,000 gallons of Total Sprinkler System Capacity

File Preview
File Preview
Click below to download for free

Text Preview

Features 7.5 HP lubricated air compressor needed for NFPA 13 required 30 fill for 2200 gallon system at 40 PSI Handles up to 3000 gallons of total sprinkler system capacity based NFPA 13 allowable leak rates for a new sprinkler system Premium nitrogen membrane UL 508A listed industrial control panel Built in Programmable Logic Controller for leak detection and air alarm systems Form C dry contacts for Building Management System BMS 80 gallon air tank and 30 gallon nitrogen tank Includes all filters relief valves automatic drains and gauges Potter Nitrogen Generator NGP 2200D M2 is specifically to provide on site high purity nitrogen for use in fire sprinkler systems When used as a supervisory gas in fire systems nitrogen slows corrosion improves the life of your and lowers maintenance costs The NGP 2200D M2 includes tank mounted air compressor nitrogen cabinet and a nitrogen tank These systems include all air filtration equipment an compressor nitrogen membrane as well as tanks required to keep generator operating at peak efficiency Potter Nitrogen Generator provide a low cost reliable and efficient method of producing minimum of 98 nitrogen at the point of usage NGP 2200D M2 utilizes nitrogen membrane technology for separation Nitrogen membranes are highly effective and a cost way of producing on site nitrogen Acting as a filter the oxygen and water vapor molecules can pass through the quickly The larger nitrogen molecules are less likely diffuse through the separator tubes therefore they continue to the separator outlet through the air maintenance device into the fire protection system As the system fills with nitrogen remaining oxygen molecules in the fire protection system are by using the Potter IntelliPurge Nitrogen Purge Valve The IntelliPurge Nitrogen Purge Valve will periodically monitor fire protection system to ensure high purity nitrogen is consistent the sprinkler system Potter NGP 2200D M2 should be installed in a dry clean and room with ambient temperatures above 50 at all times access to the front of the nitrogen cabinet for service and place the in a location that is conveniently located near fire sprinkler system and a drain Potter Nitrogen Generator should always be installed in an ventilated room Nitrogen is nontoxic and largely inert release of nitrogen gas into an enclosed space displaces the and can cause an asphyxiation hazard Inhalation of nitrogen excessive concentrations can result in unconsciousness without any symptoms detailed installation and operation instructions please refer to the Nitrogen Generator Manual 5401550 Specifications Package Size Cabinet Size Tank Size Hx Package Cabinet Weight Tank Weight x 34 x 29 x 30 x 11 x 16 lbs Supply Operating Pressure Range Purity lbs lbs in 208V 13.3A 230V 12.4A 460V three phase PSI 10 to 110 43 Class 1.4.1 or better Free of water 38 3 Point compressor oil 0.008 PPM or 01 hydrocarbons and particles 0.01 PAGE 1 OF 3 Generator8820027 REV B 9 15Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comAIRCOMPRESSORCABINETNITROGENSTORAGE TANKNITROGENDEVICEMAINTENANCEAIRAIRSTORAGE TANKfirealarmresources com Dimensions 1 COMPRESSION FITTING OUTLET PIPE TO STORAGE TANK PRESSURE TANK GAUGE 9 1 8 44 3 4 ON LIGHT SOLENOID LIGHT HORN COMPRESSION FITTING INLET PIPE TO AIR A CONNECTION OD TUBING TO CONNECT TO FLOOR DRAIN 30 FNPT OXYGEN ENRICHED OUTLET TO SAFE LOCATION 10 1 2 Dimensions 2 TANK CONDUIT PLCS 48 PRESSURE SWITCH COMPRESSION FITTING TO NITROGEN STORAGE TANK SOLENOID INLET TO AIR TANK B VALVE PRESSURE SWITCH CONNECTION OD TUBING TO CONNECT TO FLOOR DRAIN 26 3 8 28 3 8 33 3 8 VALVE 74 7 8 NPT OUTLET CONNECTION HOSE CONNECTION TO GENERATOR A 39 1 4 GALLON TANK COMPRESSION FITTING TO DRAIN SOLENOID INLET REAR OF NITROGEN GENERATOR B 15 X 88 SLOTS PLCS 15 PAGE 2 OF 3 REV B 9 15Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comNGP 2200D M2Nitrogen Generatorfirealarmresources com Tank Dimensions 3 SAFETY RELIEF VALVE COMPRESSION FITTING TO PS 2 PRESSURE SWITCH CABINET D 7 3 4 TANK GAUGE FNPT VENT FNPT PLUG FNPT NITROGEN INLET TO NITROGEN OUTLET CABINET C 44 3 8 31 25 12 1 2 45 TYP FNPT BALL VALVE 16 FNPT SYSTEM CONNECTION TO AIR MAINTENANCE DEVICE GALLON NITROGEN STORAGE TANK 2 1 2 3 8 2200D M2 2B 2200D M2 3B 2200D M2 4B PHASE 208V PHASE 230V PHASE 460V X 7 8 MOUNTING SLOTS LOCATED BOLT PATTERN PLCS APART ON A Information No Kit NGP M2 M5 IntelliPurge Nitrogen Valve Purge Valve Air Maintenance Device No PAGE 3 OF 3 REV B 9 15Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comNGP 2200D M2Nitrogen Generatorfirealarmresources com
