Potter PAD100-RM Relay Module

File Preview
File Preview
Click below to download for free

File Data

Name potter-pad100-rm-relay-module-0917862345.pdf
Type PDF
Size 1.07 MB

Text Preview

Features One 1 Form C relay contact SLC Class a Class X Class B Mounts in a standard 4 or double gang box Wiring terminals accessible when mounted in box All wiring terminals accept 22 to 12 AWG Product includes a 5 year warranty UUKL Listed for Smoke Control paD100 RM uses one 1 SLC loop address to provide one 1 C relay contact The module mounts on either a 4 square or gang box The paD100 RM includes one red LeD to indicate module status In normal condition the LED flashes when the is being polled by the control panel PAD100 RM is compatible with Potter IPA and AFC ARC addressable fire alarm control panels The PAD100 RM is an module providing one 1 Form C relay contact the Address addressable SLC device must be assigned an address The is set using the DIP switch located on the PAD100 RM The uses a single device address to identify relay contacts connecting a device to the SLC loop take the following to prevent potential damage to the panel or device Power to the device is removed Field wiring is correctly installed Field wiring has no open or short circuits Specifications Voltage SLC Standby SLC alarm Contacts Temperature Humidity no of Module per units 30VDC 0.5a 125VaC to 120 0 to 49 to 93 non condensing Options Weight 106mm L 4.17 1.14 29mm D 4 Square or gang Box lbs page 1 OF 2 Module8830084 REV D 12 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comfirealarmresources com Using Compatible Electrical Box 1 Diagram Relay Circuit 2 FACP OR MODULE NEXT MODULE 1 FORM C CONTACTS is possible that the internal relay in the PAD100 RM may be shipped in the non normal activated state To ensure that the internal relay is set to the state connect the module to the SLC loop and reset the control panel before terminating the wiring to the modules output Information Module No page 2 OF 2 REV D 12 18Potter Electric Signal Company LLC St Louis MO Phone 800 325 3936 www pottersignal comPAD100 RMRelay Modulefirealarmresources com
