Potter PVX-SL8 LED Switch Card

File Preview
File Preview
Click below to download for free

File Data

Name potter-pvx-sl8-led-switch-card-0628347519.pdf
Type PDF
Size 1.87 MB
Downloads

Text Preview

PVX Accessory Cards pVX ZM Supervised Zone Module pVX SL8 LeD Switch Card pVX IL8 LeD Input Card pVX OL8 LeD Output Card all cards connect and communicate over 10 pin ribbon cable Up to 16 total cards per panel in any combination Class B or 2 Class a speaker circuits Field selectable Vrms Field selectable with pVX SL8 for zone selection Number 3510014 Zone Module draw 24VDC input 51ma Standby 130ma all Call potter pVX ZM Supervised Zone Module is used in conjunction the pVX Series Voice evacuation panels to provide separately and protected circuits from a single speaker output The is default configured for 4 Class B circuits but may be together to provide a maximum of 64 Class B circuits pVX ZM in standard operating mode is strictly all Call On page alarm or message function all circuits activate If separate is required the pVX ZM has zone selection inputs which may activated by a N O dry contact additionally the pVX SL8 LeD Card may be employed to provide both Zone and Message by switch speaker circuit employs smart power metering to insure short conditions are isolated from the other circuits each circuit is page 1 OF 2 REV B 12 19Potter Electric Signal Company LLC St Louis MO Tech Support 866 956 1211 Customer Service 866 572 3005 www pottersignal comPVX Voice Evacuation Panels Accessory CardsPVX ZMPVX SL8PVX IL8PVX OL8firealarmresources com Momentary switches Tri color LeD green red amber for multiple functions Number 3510015 Switch Module draw On primary module battery back up 3ma Standby all Call potter pVX SL8 LeD Switch Module provides switch selection message activation paging and control functions be programmed for page zone control LeDs for switches assigned LeD will indicate amber if the associated speaker circuit is in a condition can be programmed to control corresponding points on the Switch LeDs will indicate steady Red on activation Number 3510016 Input Module draw On primary module battery back up 3ma Standby all Call potter pVX IL8 LeD Input Module can be used for page zone message selection and control functions The inputs an external N O dry contact pVX IL8 are typically used message zone activation from an outside system such as Severe on the pVX OL8 On activation the corresponding LeD will red Number 3510017 Output Module draw On primary module battery back up 3ma Standby all Call N O pVX OL8 LeD Output Module provides solid state N O dry It can also be separately tied to a voltage 0 24VDC with voltage used as a drive point or trigger Outputs 1 4 and 5 8 may different voltage references if desired The pVX OL8 outputs may like pTT alarm or control Input points Red LeD for multiple functions Input points Red LeD page 2 OF 2 8830072 REV B 12 19Potter Electric Signal Company LLC St Louis MO Tech Support 866 956 1211 Customer Service 866 572 3005 www pottersignal comPVX Voice Evacuation Panels Accessory Cardsfirealarmresources com
