SH 120 SERIES MOUNT WEATHER PROOF UL Listed 120 VAC operation Outdoor and indoor 6 sound output settings Pre wire back plate Universal back plate mounting single gang double gang octagon or 4 square Single screw mounting Low current draw BBX 5 weather proof backbox included SH 120 Series Select A Strobe Horn is designed to audible and or visual signals for fire and burglar alarm systems and notification signals for the purpose of life and protection SH 120 are operable with a 120 VAC system between 96 and 132 VAC They can be interfaced with pull stations switches and sprinkler systems for residential commercial industrial applications SH Series combines a selective three horn tone and provides continuous tone or temporal pattern code 3 when constant is applied series is available with a red or white housing and a clear lens Installation must comply in accordance with applicable standards BOX Information Number Number strobe horn chime strobe horn chime box included back box 15 1 Specifications contractor shall provide and install a Potter SH 120 strobe The unit shall operate on a nominal 120 VAC input and have a horn setting The unit shall be listed to UL standard 1638 Signaling for indoor and outdoor applications The strobe have a 110 candela rating The unit shall include a weather back box as part of the standard package The device shall a universal pre wire mounting plate for the ease of connection universal back plate shall allow for connection to a single gang gang 4 square standard or deep box BBK 1 weather proof back box or the BBX 5 custom weather proof back box The horn be listed to UL standard 464 Audible Signaling devices Electric Signal Co LLC St Louis MO Cust Service 866 240 1870 Tech Support 866 956 1211 Canada 888 882 1833 www pottersignal com IN USA MKT 8910015 REV B 1 OF 2 Diagram inches mm AC Next 16 2 voltage may be present inside the light assembly even power is not connected If access to the component board required removal or replacement the capacitor must be by touching a wire to both ends of the flashtube NOT attempt to touch or move the assembly until the has been discharged SERIES MOUNT WEATHER PROOF 127 View 157.7 85.7 View 891 2 BBX 5 OUTDOOR BACK BOX 85.7 139.7 View 2 View 891 1 4 ea x screws VAC RMS Current varies horn setting cd axis per VAC to 151 to 66 housing lens Setting 1 OFF 0 RMS Reverberant per UL 464 10Ft IN USA MKT 8910015 REV B 2 OF 2
