A Brand SERIES STROBE LIGHTS Designed to meet UL 1638 Visual Appliance Private Mode Polarized using ltered DC or un ltered FWR input voltage 12 and 24V DC models Solid state circuitry and a xenon ash tube Impact resistant black abs base Interchangeable polycarbonate lens UL listed AWG 18 wire leads 10.6 long Optional surface mount plate model SP SL1B Replacement interchangeable lens model SL LG SL 5 series strobes are a high performance high intensity solid state strobe designed for applications where 360 visual annunciation is The strobe light is UL 1638 approved and is listed for general utility signaling The strobe is polarized for connecting to supervised and is designed with a xenon ash tube The SL 5 is a high pro le strobe with a low current draw of 250mA at 24V DC The strobe be used as a stand alone or in combination with other signaling devices to provide a visual veri cation signal The SL 5 series strobes are for use in areas such as parking facilities schools corridors apartments of ce buildings restaurants hotels and any other where effective visual warning is required Installation must comply in accordance with applicable standards and or all state and electrical codes and authority having jurisdiction Structure LENS NEXT DEVICE OR LINE RESISTOR Number Number Lens Current Current Rate 12A 12B 12C 12R 24A 24B 24C 24R 12V DC DC DC DC DC DC DC DC 122 49 Electric Signal Company 2081 Craig Road St Louis MO 63146 4161 Phone 800 325 3936 Canada 888 882 1833 www pottersignal com IN USA MKT 8850061 REV B 1 OF 2 SERIES STROBE LIGHTS Brand Speci cations visual alarm indicating appliance shall be Amseco model SL 5 or equivalent device strobe shall be available in amber blue clear and red lens strobe shall be listed in compliance with UL 1638 Visual Appliance Private Mode Emergency and General Utility for use in indoor signaling strobe shall operate from a non coded regulated DC supply or full wave recti ed un ltered supply signaling strobe shall be designed to produce a signal ash of 50 90 ashes per minute with continuously applied voltage strobe shall be capable of surface mounting to a 4 square box using Amseco SP SL1B plate signaling devices shall be installed as per plans and speci cations millimeters Mounting 269 holes for 2 long IN USA 8850061 REV B 2 OF 2
